Teledyne LeCroy ZD1500 Differential probe 1.5 GHz 1:1 30 V
EAN:
Part number:
Item no:
Highlights & Details
Teledyne LeCroy ZD1500 Differential probe 1.5 GHz 1:1 30 V
- 1:1
- Bandwidth 1.5 GHz
Technical specifications
- Slew rate
0.27 ns
- Input capacity
1 pf
- Input resistance
120 kΩ
- Type
Differential
- Compatible with (details)
WaveSurfer®
WaveRunner®
WavePro®
Wavemaster® firmware 6.4.1.x and higher
- Divider voltage ratio
1:1
Manufacturer's standards (no certificate)
- Reading category
CAT I
- Nominal voltage
30 V
- Bandwidth
1.5 GHz
- Product type
Differential probe
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 103154 Teledyne LeCroy ZD1500 Differential probe 1.5 GHz 1:1 30 V
Description
The differential probe works like 2 probes in one. It enables the measurement of the voltage differential between two freely definable measurement points. A fixed reference point (ground) is not required.
This text is machine translated.
This text is machine translated.
Features
- Fully integrate into LeCroy-DSOs without additional power source.
- A variety of contact can be, selectable test tips/gripper.
Scope of delivery
- Y-adapter cable · 2 Einlot-Y-adapter cable · 2 Mini gripper · 2 Micro gripper · 4 test tips · 4 extensions (2x short/2x long) · 2 test tips saver · 4 spring-loaded mass adapter (2 x short/2x long) · Rotating probe tip adapter · 2 narrow IC Test Tips · Probe calibration device · Probe holder · User manual · Calibration certificate.
