TracoPower TDN 5-0922WISM DC/DC converter (SMD) 210 mA 5 W No. of outputs: 2 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 34.99 / piece)
€ 34.99
incl. VAT
14-day return policy included
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TDN 5WISM
- Min. input voltage
4.5 V DC
- Input voltage (max.)
13.20 V DC
- No. of outputs
2 x
- Max. output current
210 mA
- Output current (max.) - rounded
210 mA
- Efficiency (max.)
83 %
5 W
- Insulation voltage
1600 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 14.20 x 9.10 x 10.20 mm
- Height
10.20 mm
- Length
14.20 mm
- Width
9.10 mm
- RoHS-compliant
Yes
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
2.70 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2195703 TracoPower TDN 5-0922WISM DC/DC converter (SMD) 210 mA 5 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 2195703 TracoPower TDN 5-0922WISM DC/DC converter (SMD) 210 mA 5 W No. of outputs: 2 x Content 1 pc(s)
