TracoPower TEP 75-2415WI-CMF DC/DC converter (module) 24 V DC 24 V DC 3.2 A 75 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 214.29 / piece)
€ 214.29
plus VAT.
Technical specifications
- Product type
DC/DC converter (module)
- Type
TEP 75-2415WI-CMF
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
24 V DC
- Max. output current
3.2 A
- Output current (max.) - rounded
3.2 A
- Efficiency (max.)
87 %
75 W
- Insulation voltage
1600 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 85 x 61 x 38.8 mm
- Height
38.8 mm
- Length
85 mm
- Width
61 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Weight
97 g
- Content
1 pc(s)
- Type
TEP 75-2415WI-CMF
Documents & Downloads
Datasheet
Datasheet 1510117 TracoPower TEP 75-2415WI-CMF DC/DC converter (module) 24 V DC 24 V DC 3.2 A 75 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510117 TracoPower TEP 75-2415WI-CMF DC/DC converter (module) 24 V DC 24 V DC 3.2 A 75 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1510117 TracoPower TEP 75-2415WI-CMF DC/DC converter (module) 24 V DC 24 V DC 3.2 A 75 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510117 TracoPower TEP 75-2415WI-CMF DC/DC converter (module) 24 V DC 24 V DC 3.2 A 75 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, chassis mounting with screw terminal block and filter according to EN 55022, class A. Approvals for railways according to EN 50155, short-circuit proof, external on/off, adjustable output voltage with ext. Resistance, reverse polarity protection at the entrance.
