TracoPower TMDC 06-4823 DC/DC converter 200 mA 6 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 47.05 / piece)
€
Technical specifications
- Type
TMDC 06-4823
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
85 %
6 W
- Insulation voltage
3000 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 53 x 34 x 26.50 mm
- Height
26.50 mm
- Length
53 mm
- Width
34 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
49 g
- Product type
DC/DC converter
