TracoPower TOP 200-124 SMPSU 24 V DC 8.3 A 200 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 154.99 / piece)
€ 154.99
incl. VAT
14-day return policy included
Highlights & Details
TracoPower TOP 200-124 SMPSU 24 V DC 8.3 A 200 W
- 8.3 A
- 200 W
- Highest power density in industry standard 7.62 x 12.70 cm (3 x 5")
- Switching power supplies 200 W with convection cooling
- Connector with connector assembly (Molex)
- Universal power input 85-264 V/AC
- Harmonic limits according to EN 61000-3-2
- Secured against energetic recovery systems
- Security class I and II
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
8.3 A
- Output current (max.) - rounded
8.3 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 127 x 76.2 x 34 mm
- Output voltage (max.)
24 V DC
200 W
- No. of outputs
1 x
- Output current 1
8.3 A
- Type
open
- Weight
315 g
- Width
76.2 mm
- Height
34 mm
- Length
127 mm
- Type
TOP 200-124
200 W
- Connection
Connector (Molex)
- PFC
Yes
- Input voltage
85 - 264/120 - 240 V AC
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 514674 TracoPower TOP 200-124 SMPSU 24 V DC 8.3 A 200 W
Datasheet 514674 TracoPower TOP 200-124 SMPSU 24 V DC 8.3 A 200 W
User & Safety Instructions
User & Safety Instructions 514674 TracoPower TOP 200-124 SMPSU 24 V DC 8.3 A 200 W
Warranty Terms
Warranty Terms 514674 TracoPower TOP 200-124 SMPSU 24 V DC 8.3 A 200 W
Description
The highest power density in the industry standard 76.2 x 127 mm (3.0 " x 5.0 " ) is the outstanding feature. The power unit can be operated with an output power of up to 200 W with convection cooling in an industrial operating temperature range of -25 to +70 ° C. This feature is achieved by advanced technology and an extremely high efficiency, which makes the use of an additional cooling fan unnecessary.
Features
- Ultra compact oen fame switching SMPS
- Connector with connector assembly (Molex)
- Overvoltage protection
- Interference according to EN 55022, class B and EN 61000-3-2 (PFHC)
- International safety standards/ permissions
- Network-/load regulation ±1% max
- Remaining ripple< 120 m V pp
- Current limit 120 - 150%
- Operation temperature -25 till +70 °C, reduction of performance above 50 ºC
- Safety/approvals according to IEC/EN 60950
- Efficiency 90-93 %.
