TracoPower TOP 60254 PSU 5 V DC 6 A 55 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 59.99 / piece)
€ 59.99
incl. VAT
Only 1 Piece(s) available
Highlights & Details
AC/DC power supply, TOP-Series
- Output 5 V DC / 6 A
- Power 55 W
- Connector
Technical specifications
- Product type
PSU
- Input voltage (max.)
264 V AC
- Max. output current
6 A
- Output current (max.) - rounded
6 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 30.0 x 50.8 x 101.6 mm
- Output voltage (max.)
5 V DC
- Connection
Connector
55 W
- No. of outputs
2 x
- Type
open
- Weight
205 g
- Width
50.8 mm
- Height
101.6 mm
- Length
30.0 mm
- Type
TOP 60254
- Output current 2 (max.)
1.5 A
- Output current 2 (min.)
0 A
- Output current (min.)
0 A
- Output voltage 2 (max.)
24 V DC
- Output voltage 2 (min.)
24 V DC
- Output voltage (min.)
5 V DC
- No. of inputs
1 x
- Max. temperature
70 °C
- Min. temperature
-10 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1591555 TracoPower TOP 60254 PSU 5 V DC 6 A 55 W
Datasheet 1591555 TracoPower TOP 60254 PSU 5 V DC 6 A 55 W
User & Safety Instructions
User & Safety Instructions 1591555 TracoPower TOP 60254 PSU 5 V DC 6 A 55 W
Warranty Terms
Warranty Terms 1591555 TracoPower TOP 60254 PSU 5 V DC 6 A 55 W
