TRU COMPONENTS TC-KT48 PID Temperature controller B, E, J, K, N, R, S, T, Pt100 -200 up to 1820 °C 5 A relay (L x W x H)
EAN:
Part number:
Item no:
Product type
Temperature controller
Thermostat type
PID
Operating voltage
100 V AC
240 V AC
Max. temperature reading
1820 °C
Outputs (thermostats)
5 A relay
Number
Total (€ 37.81 / piece)
€ 37.81
plus VAT.
14-day return policy included
Highlights & Details
PID temperature controller 48x48 mm, thermocouple K, E, J, S, R, B, N, T, Cu50, Pt100, Out: Relay 250 V/5 A
- Dual heating and cooling modes
- Compact dimensions: 48 x 48 x 82 mm
- Wide temperature control range: -200 °C to 1820 °C
- Integrated over-temperature alarm
- Compatible with multiple sensor types: B, E, J, K, N, R, S, T, Pt100, Cu50
- Relay output: 250 V / 5 A
- Power supply: 100 - 240 V AC, 50/60 Hz
Our service for you
Technical specifications
- Product type
Temperature controller
- Type
TC-KT48
- Thermostat type
PID
- Operating voltage
100 V AC
240 V AC
- Reading range
-200 up to 1820 °C
- Max. temperature reading
1820 °C
- Min. temperature reading
-200 °C
- Outputs (thermostats)
5 A relay
- Dim
(L x W x H) 82 x 48 x 48 mm
- Height
48 mm
- Length
82 mm
- Width
48 mm
- Sensor type
B
E
J
K
N
R
S
T
Pt100
- Manufacturer part #
TC-14124748
- Recess depth
82 mm
- Mounting type
Recess-mount
- Assembly dimensions
45x45 mm
- Plastic free packaging
Plastic-free packaging
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3531187 TRU COMPONENTS TC-KT48 PID Temperature controller B, E, J, K, N, R, S, T, Pt100 -200 up to 1820 °C 5 A relay (L x W x H)
