Name: USB-C® connection cable, TB4, UltraFlex, 1m Plug 10080133 BKL Electronic Content: 1 pc(s)
Brand: BKL Electronic
SKU: 3280542
Availability: InStock

Two black USB-C cables with 'NRL' printed on them, running parallel to each other, over a white background.

Product type

USB-C cable

Connector type

Plug

USB type

C®

Connector standard

USB-C® plug

Type

10080133

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 4 Nov

14 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 38.99 / piece)

€ 38.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

USB-C® connection cable, TB4, UltraFlex, 1m

It supports among others :
PCI Express (32 Gbps)
USB4 40Gbps
DisplayPort 1.4 up to 2x 4K or 1x 8K (HBR2, MST)
Thunderbolt networking up to 10 Gbit/s.
Power Delivery (20V/5A)

Technical specifications

Type: 10080133

Product type: USB-C cable

Connector type: Plug

USB type: C®

Connector standard: USB-C® plug

Connection: USB Typ C®

Type A: USB-C® plug

Type B: USB-C® plug

Case material: Soft PVC

Manufacturer part #: 10080133

Factory colour: Black

Content: 1 pc(s)

Cable Ø (max.): 4.80 mm

Cable Ø range: 4.80 mm (max)

Cable length: 1 m

Contact material: Gold plated

Material: Copper

: 10 Gbps

Length: 1 m

RoHS-compliant: Yes

Features: gold-plated contacts

Documents & Downloads

Datasheet

Datasheet 3280542 USB-C® connection cable, TB4, UltraFlex, 1m Plug 10080133 BKL Electronic Content: 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3280542 USB-C® connection cable, TB4, UltraFlex, 1m Plug 10080133 BKL Electronic Content: 1 pc(s)

Description

Connect your laptop with only one cable to your docking station and you get access to all the important interfaces. For devices with higher power requirements you can also charge your laptop / ultrabook at the same time with up to 100 watt (depending upon the hardware used). With the Thunderbolt wake-up function you can start your laptop or call your end device out of sleep mode with the help of your Thunderbolt 4 docking station. Thunderbolt 4 also supports Daisy Chaining, with Daisy Chain you can cascade up to 6 Thunderbolt 4 devices.

This text is machine translated.

Features

Connections: USB-C® connector to USB-C® connector
Supports DisplayPort 1.4 (up to 8K/6K/60Hz, 2x 4K/60Hz), PD up to 100W (20V/5A), SuperSpeed USB 5/10/20Gbps, PCI Express 3.0, bi-directional data transfer, daisy chain (up to 6 devices), Thunderbolt bus Power up to 15W, networking up to 10 Gbps (peer-to-peer), wake-up from sleep via Thunderbolt 3 or 4 docking station,
Bandwidth up to 40 Gbps
EJ903W (Intel® certified) chipset
Compatible with Thunderbolt 3, Thunderbolt 4, USB 6
Number of shields: 3-fold
Core material: Tin-plated + silver-plated copper
Cable setup: Coaxial
Plug: Cast with metal shielding
Contact surface: Gold-plated pins 15µ
Plug housing: Metal (aluminum alloy) integrated in "Molding" the cases are securely connected to the plug
Cable type: Round cable

Hints

Info: Not all devices with USB-C® interface support the 100 watt fast charging capability (PD 3.0), the transmission of video signals (DP alternative mode) or the data transfer of 40 Gbit/s (USB4 40Gbps / Thunderbolt 4). For more information, contact your device manufacturer.

Description

Features

Connections: USB-C® connector to USB-C® connector
Supports DisplayPort 1.4 (up to 8K/6K/60Hz, 2x 4K/60Hz), PD up to 100W (20V/5A), SuperSpeed USB 5/10/20Gbps, PCI Express 3.0, bi-directional data transfer, daisy chain (up to 6 devices), Thunderbolt bus Power up to 15W, networking up to 10 Gbps (peer-to-peer), wake-up from sleep via Thunderbolt 3 or 4 docking station,
Bandwidth up to 40 Gbps
EJ903W (Intel® certified) chipset
Compatible with Thunderbolt 3, Thunderbolt 4, USB 6
Number of shields: 3-fold
Core material: Tin-plated + silver-plated copper
Cable setup: Coaxial
Plug: Cast with metal shielding
Contact surface: Gold-plated pins 15µ
Plug housing: Metal (aluminum alloy) integrated in "Molding" the cases are securely connected to the plug
Cable type: Round cable
