WAGO 750-506/000-800 PLC digital output module 750-506/000-800 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 65.54 / piece)
€ 65.54
plus VAT.
14-day return policy included
Technical specifications
- 2DO 24V DC 0,5A DIAGNOSE/R
- Product type
PLC digital output module
- Type
750-506/000-800
- No. of outputs (max.)
2
- Operating voltage
24 V DC
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
750-506/000-800
- Weight
49.5 g
- Factory colour
Light grey
- Mounting type
DIN rail
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 191917 WAGO 750-506/000-800 PLC digital output module 750-506/000-800 1 pc(s)
User & Safety Instructions
User & Safety Instructions 191917 WAGO 750-506/000-800 PLC digital output module 750-506/000-800 1 pc(s)
Description
24 V DC, 0.5 A/diagnostics, positive switch, short circuit proof, light gray.
