WAGO 750-628 PLC supply module 750-628 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 144.99 / piece)
€ 144.99
incl. VAT
14-day return policy included
Technical specifications
- Color: light gray
- Cross-section 0.08 - 2.5 mm²
- AWG 28 - 14
- CAGE CLAMP ® connection:
- Stripping length: 8 - 9 mm
- Internal power consumption: 150 mA
- Installation type: TS 35
- Operating temperature: 0 to + 55 °C
- Product type
PLC supply module
- Interfaces
RJ 45
- Type
750-628
- No. of inputs (max.)
1
- No. of outputs (max.)
1
- Operating voltage
24 V DC
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
750-628
- Weight
74.5 g
- Connection
Spring-loaded heavy duty connector
- Factory colour
Multicolour
- Mounting type
DIN rail
- Inputs / outputs
2 x RJ-45 socket (input + Output)
24
100 mm
69.8 mm
FALSE
DC
FALSE
0
0
0
0
2
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
TRUE
Spring clamp connection
TRUE
None
None
FALSE
FALSE
IP20
FALSE
FALSE
0
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
24-24 V
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 191996 WAGO 750-628 PLC supply module 750-628 1 pc(s)
User & Safety Instructions
User & Safety Instructions 191996 WAGO 750-628 PLC supply module 750-628 1 pc(s)
Description
Light gray.
