WAGO 750-653/025-018 PLC serial interface 750-653/025-018 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 525.00 / piece)
€ 525.00
incl. VAT
14-day return policy included
Technical specifications
- RS 485 9600/N/8/1/5Byte/Cont./T
- Product type
PLC serial interface
- Interfaces
RS 485
Terminals
- Type
750-653/025-018
- No. of inputs (max.)
1
- No. of outputs (max.)
1
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+60 °C
- Min. ambient temperature
-20 °C
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
750-653/025-018
- Weight
48.5 g
- Mounting type
DIN rail
- Operating voltage
Via the system voltage DC/DC
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 192060 WAGO 750-653/025-018 PLC serial interface 750-653/025-018 1 pc(s)
User & Safety Instructions
User & Safety Instructions 192060 WAGO 750-653/025-018 PLC serial interface 750-653/025-018 1 pc(s)
Description
RS-485 Interface 9600/N/8 / 1 / 5 byte cont., external light gray.
This text is machine translated.
This text is machine translated.
