WAGO 769-127 Edge connector (sockets) 5 mm Pull spring Configuration: L Grey 10 pc(s) Package
Packaging type
Package
Product type
Edge connector (sockets)
Connection
Pull spring
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
4 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
2-conductor terminal block
- 769-127
- Industrial packaging, pack of 10
- This text is machine translated.
Technical specifications
- Packaging type
Package
- Product type
Edge connector (sockets)
- Features
+ CAGE CLAMP®
- Connection
Pull spring
- Configuration
L
- Cross section (flexible) (min.)
0.08 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.08 mm²
- Cross section (inflexible) (max.)
4 mm²
- AWG (min.)
28
- AWG max.
12
- Clamp width
5 mm
- No. of rows
7
- Pins per row
2
- Number of pins
14
- Factory colour
Grey
- Nominal current
32 A
- Nominal current - rounded value
32 A
- Nominal voltage
500 V
- Min. stripping length
8 mm
- Stripping length (max.)
8 mm
- Manufacturer part #
769-127
- Content
10 pc(s)
- Industrial packaging
Yes
- Type
769-127
- Dim
(L x W x H) 35 x 35 x 45.20 mm
- Width
35 mm
- Height
45.20 mm
- Length
35 mm
- Contamination level
3
- Weight
36.437 g
- Flammability rating
V0
- Insulation material
Thermoplastic
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 655597 WAGO 769-127 Edge connector (sockets) 5 mm Pull spring Configuration: L Grey 10 pc(s) Package
User & Safety Instructions
User & Safety Instructions 655597 WAGO 769-127 Edge connector (sockets) 5 mm Pull spring Configuration: L Grey 10 pc(s) Package
