WAGO 787-1014 Rail mounted PSU (DIN) 24 V DC 2 A No. of outputs:2 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 174.99 / piece)
€ 174.99
incl. VAT
14-day return policy included
Highlights & Details
COMPACT DC-DC CONVERTER 110V/24V 2A
- Primary-switched power supply
- Prepared for devices and systems of protection class II
- Natural cooling by natural convection in horizontal Mounting position
- Stepped profile, ideal for service distribution or system distributor
- Parallel switching, daisy-Chainable
- Galvanically isolated output voltage (SELV) according to EN 60950-1/UL 60950-1
Technical specifications
- Weight: 250 g
- Height: 89 mm
- Connections: spring terminals
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
77 V DC
- Output voltage
24 V DC
- Input voltage (max.)
140 V DC
- Max. output current
2 A
- Output current (max.) - rounded
2 A
- Output type (power supply units)
Fixed voltage
- Phases
1
- Output voltage (nominal)
24 V DC
- No. of outputs
2 x
- Connection
Spring-loaded terminal
- Dim
(L x W x H) 59 x 72 x 89 mm
- Weight
250 g
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Manufacturer part #
787-1014
- Content
1 pc(s)
- PSU features
Regulated
- Width
72 mm
- Height
89 mm
- Length
59 mm
- Type
EPSITRON
- Connections
Spring terminals
- Output current (details)
2000 mA
- Input voltage
110 VDC
- Output voltage 1
24 V DC
72
89 mm
72 mm
FALSE
FALSE
4
DC
Spring clamp connection
TRUE
IP20
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1214647 WAGO 787-1014 Rail mounted PSU (DIN) 24 V DC 2 A No. of outputs:2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1214647 WAGO 787-1014 Rail mounted PSU (DIN) 24 V DC 2 A No. of outputs:2 x Content 1 pc(s)
Description
Primary-switched power supplies EPSITRON ® COMPACT power; output voltage 24 V DC; 2 A
This text is machine translated.
This text is machine translated.
Features
- Surge protection: Varistor (input side)
- Internal protection circuit,< DC 40V (on the output side in the event of a fault)
- Standards/regulations: EN 60950, EN 61204-3, UL 60950, UL 508*, GL * * (in preparation)
Hints
Height: 89 mm
Weight: 250 g
Connections: spring terminals
