Name: Weidmüller 1877650000 Pin strip Total number of pins 8 No. of rows 1 285 pc(s)
Brand: Weidmüller
SKU: 1765739
Availability: BackOrder

Black plastic plug with eight contacts in two rows, suitable for electronic connections or device interfaces.

Image similar

Product type

Pin strip

Total no. of pins

5.08 mm

Content

285 pc(s)

Total number of pins

Datasheet (PDF)

Dispatches on Fri 11 Dec

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 285 pc(s))

Set(s)

Total (€ 4.02 / piece)

€ 1,145.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Pcb connector, connector pin strip, the side closed, THT/THR soldering, 5.08 mm, number of poles: 8, 270°, 1.5 mm, tinned, black, Tape (Ø 33

Total number of pins 8
No. of rows 1
Content 285 pc(s)

Our service for you

Technical specifications

Depth: 12 mm
PCB mounting: THT/THR solder connection
Outlet angle: 270°
Number of solder pins per pin: 1
Mounting hole diameter 1.4 mm
Insulating material: LCP GF
Storage temperature: -25 °C to +55 °C.
Insertion force/pole 9 N.
Pulling power/pole: 7 N.
Soldering pin length 1.5 mm

Product type: Pin strip

Total no. of pins: 8

Total number of pins: 8

No. of rows: 1

CS: 5.08 mm

Nominal current: 18.5 A

Nominal current - rounded value: 18.5 A

Pins per row: 8

Connection: THT
THR
Soldering

Factory colour: Black

Case material: PA

Manufacturer part #: 1877650000

Content: 285 pc(s)

Contact material: CuMg

Width: 43.84 mm

Height: 12.5 mm

Max. temperature: +100 °C

Min. temperature: -50 °C

Type: SL-SMT 5.08HC/08/270GH 1.5SN BK RL

Dim: (W x H) 43.84 mm x 12.5 mm

Resistance: 5 mΩ

Insulation resistance: 100 MΩ

Connector contact surface: Tin plated

Dimensions: 43.84 mm x 12.5 mm x 12 mm

Nominal voltage: 300 V

Number of pins: 8

RoHS-compliant: Yes

Mating cycles: 25

Pin length: 1.5 mm

UKCA: not relevant
