Name: Yageo Nexensos 32207691 M 213 PT100 Platinum temperature sensor -50 up to +300 °C 100 Ω 3850 ppm/K Radial lead
Brand: Yageo Nexensos
SKU: 2482849
Availability: BackOrder

Blue ceramic capacitor with two wire leads, vertically positioned. Used in electronic circuits.

Product type

Platinum temperature sensor

Model

PT100

Temperature reading range (max.)

+300 °C

Connector

Solder pins

Type

Radial lead

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Thu 5 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 7.99 / piece)

€ 7.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Platinum temperature sensors, wired

Slim design for narrow mounting environments
Excellent long-term stability and minimum deviation
High accuracy and interchangeability
High vibration and shock resistance
Optimized for welding, soldering and crimping

Technical specifications

DIN EN 60751
Measuring current 0.3 to 1 mA
Packaging: Plastic bag
Self-heating 0.6 K/mW at 0 °C.
Assembly and connection technology: Welding, crimping, brazing
Connecting wires: NiPt sheathed wire
Tensile strength of connecting wires: ≥ 7 N.

Product type: Platinum temperature sensor

Type: M 213

Model: PT100

Temperature reading range (min.): -50 °C

Temperature reading range (max.): +300 °C

Temperature reading range: -50 up to +300 °C

Connector: Solder pins

Orientation (connectors): Radial

Cable length: 10 mm

Type: Radial lead

Accuracy class: A (F0.15)

Resistance: 100 Ω

Temperature coefficient: 3850 ppm/K

Length: 11.7 mm

Width: 1.25 mm

Height: 0.8 mm

Dim: (L x W x H) 11.7 x 1.25 x 0.8 mm

Variants(All information include VAT, plus shipping costs)

Model

Resistance

Temperature reading range (max.)

Yageo Nexensos 32207691 M 213 PT100 Platinum temperature sensor -50 up to +300 °C 100 Ω 3850 ppm/K Radial lead

Item no:2482849

Dispatches on Thu 5 Nov

Conrad Electronic

This article

PT100

100 Ω

+300 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 7.99^*

Yageo Nexensos 32207690 M 213 PT100 Platinum temperature sensor -70 up to +500 °C 100 Ω 3850 ppm/K Radial lead Bag

Item no:2482871

Fast track dispatch on Thu 29 Oct

379 Piece(s)Conrad Electronic

PT100

100 Ω

+500 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 4.29^*

Yageo Nexensos 32207692 M 213 PT100 Platinum temperature sensor 0 up to +150 °C 100 Ω 3850 ppm/K Radial lead Bag

Item no:2482840

Fast track dispatch on Thu 29 Oct

410 Piece(s)Conrad Electronic

PT100

100 Ω

+150 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.79^*

Yageo Nexensos 32207695 M 213 PT1000 Platinum temperature sensor -70 up to +500 °C 1000 Ω 3850 ppm/K Radial lead Bag

Item no:2482870

Fast track dispatch on Thu 29 Oct

358 Piece(s)Conrad Electronic

PT1000

1000 Ω

+500 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 5.49^*

Yageo Nexensos 32208213 M 416 PT100 Platinum temperature sensor -70 up to +500 °C 100 Ω 3850 ppm/K Radial lead

Item no:2482881

Fast track dispatch on Thu 29 Oct

16 Piece(s)Conrad Electronic

PT100

100 Ω

+500 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.29^*

Yageo Nexensos 32208392 M 422 PT100 Platinum temperature sensor -70 up to +500 °C 100 Ω 3850 ppm/K Radial lead Bag

Item no:2482885

Fast track dispatch on Thu 29 Oct

688 Piece(s)Conrad Electronic

PT100

100 Ω

+500 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 4.79^*

Yageo Nexensos 32208414 M 422 PT500 Platinum temperature sensor -70 up to +500 °C 500 Ω 3850 ppm/K Radial lead Bag

Item no:2482884

Dispatches on Thu 5 Nov

Conrad Electronic

PT500

500 Ω

+500 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 4.79^*

Yageo Nexensos 32208439 M 1020 PT1000 Platinum temperature sensor -50 up to +300 °C 1000 Ω 3850 ppm/K Radial lead Tape

Item no:2482868

Fast track dispatch on Thu 29 Oct

105 Piece(s)Conrad Electronic

PT1000

1000 Ω

+300 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 6.49^*

Yageo Nexensos 32208440 M 220 PT100 Platinum temperature sensor -70 up to +500 °C 100 Ω 3850 ppm/K Radial lead

Item no:2482872

Fast track dispatch on Thu 29 Oct

302 Piece(s)Conrad Electronic

PT100

100 Ω

+500 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 1.49^*

Yageo Nexensos 32208483 M 1020 PT1000 Platinum temperature sensor 0 up to +150 °C 1000 Ω 3850 ppm/K Radial lead

Item no:2482847

Fast track dispatch on Thu 29 Oct

436 Piece(s)Conrad Electronic

PT1000

1000 Ω

+150 °C

Piece(s)

Minimum order quantity: 1

Multiple: 1

€ 2.29^*

Documents & Downloads

Datasheet

Datasheet 2482849 Yageo Nexensos 32207691 M 213 PT100 Platinum temperature sensor -50 up to +300 °C 100 Ω 3850 ppm/K Radial lead

User & Safety Instructions

User & Safety Instructions 2482849 Yageo Nexensos 32207691 M 213 PT100 Platinum temperature sensor -50 up to +300 °C 100 Ω 3850 ppm/K Radial lead

Description

This wired platinum temperature sensor is typically used in automotive applications, domestic appliances, air-conditioning and heating technology, process industry and medical technology.
