Buy Bicker Elektronik IUPS-401 UPS 400 VA

Two uninterruptible power supply (UPS) devices from Bicker.de, Model NUPS-401, in white and black. They provide continuous power supply. Additional equipment is visible in the background.

User interface of the 'UPSilion 2000 for Windows' software with displays for input voltage, output voltage, battery status, and UPS load.

Two electronic device enclosures, one in white and one in black, with ventilation slots and operational indicators on the front panel.

A white server chassis with a transparent, sealed glass door provides access to drives and interfaces on the front panel.

'A 2-euro coin is used to unlock the front panel of an enclosure. Two different power supply models are shown underneath.'

1/7

Datasheet (PDF)

Fast track dispatch on Fri, 11 Sep

2 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 247.90 / piece)

€ 247.90

plus VAT.

Only 2 Piece(s) available

Report legal concerns

Bicker PC-Installation USB UPS 400 VA

Highlights & Details

UPS for installation in the PC-drive slot
With USB-interface and reboot function

Technical specifications

Maintenance-free lead-acid batteries 2x 6 V / 3 Ah, 0 to +40 °C ambient temperature

Product type: UPS

Nominal power: 400 VA

No. of outputs: 2 x

with surge protection: 2

of which battery-buffered: 2

Output: IEC socket

Bridging time normal load: 5 min

Bridging time, max load: 2 min

Type: IUPS-401

Width: 146 mm

Height: 42 mm

Depth: 253 mm

Weight: 2.75 kg

Range of uses: Installation in home and industrial computers

Plug type: Cold devices

Documents & Downloads

Datasheet

Datasheet 990780 Bicker Elektronik IUPS-401 UPS 400 VA

User & Safety Instructions

User & Safety Instructions 990780 Bicker Elektronik IUPS-401 UPS 400 VA

Information

Information 990780 Bicker Elektronik IUPS-401 UPS 400 VA

Conformity certificate

Conformity certificate 990780 Bicker Elektronik IUPS-401 UPS 400 VA

Description

The UPS USV IUPS-401 is meant for installation in the PC contrary to the conventional uninterrupted power supplies. UPS and PC thereby form a space-saving and a compact unit. The IUPS-401 can be installed easily in a drive slot and is absolutely user-friendly in its handling. Via the interface and by means of the UPS management-software "UPSilon 2000" the computer is shutdown and switched off when the power fails. With load sensor for protecting the batteries.

Features

Reboot function: Returns the mains voltage during the mains failure and during the already initiated shutdown phase of Windows®, so that the UPS switches of the PC (after the shutdown time is over) and switches it on again after about 30 seconds (please note the BIOS-settings of the motherboard)

Scope of delivery

Power cable
Integriated UPS with battery
Slot plate with USB-board
CD UPSilon 2000
2x USB and 1 connection cable
2x front plates (grey and black)
User manual
