Bosch Professional GOL 32 G Level Range (max.): 120 m Optical magnification (max.): 32 x
EAN:
Part number:
Item no:
Number
Total (€ 239.50 / piece)
€ 239.50
plus VAT.
Optical levelling device GOL 32 G Professional
Highlights & Details
- IP 54
Technical specifications
- Unit of measurement (scaling): 360°/400 Gon
- Dust and splash-water protection: IP54
- lens opening: 36 mm
- Field of view: 1°30'
- Minimum measurement range: 0.3 m
- compensator (levelling range): 15"
- high accuracy in a single measurement: 1 mm/30 m
- Product type
Level
- Range (max.)
120 m
- Optical magnification (max.)
32 x
- Tripod thread mount
5/8"
- Length
215 mm
- Width
135 mm
- Height
145 mm
- Dim
(L x W x H) 215 x 135 x 145 mm
- Weight
1.5 kg
Manufacturer's standards (no certificate)
- Type (Bosch)
Bosch Professional (blue)
- Type
GOL 32 G
- Type
GOL 32 G Professional
- Reading range
120 m
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 377019 Bosch Professional GOL 32 G Level Range (max.): 120 m Optical magnification (max.): 32 x
Warranty Terms
Warranty Terms 377019 Bosch Professional GOL 32 G Level Range (max.): 120 m Optical magnification (max.): 32 x
Description
Features
- Precise work on long distances thanks to the integrated collimator for coarse goal setting and the focusing screw to focus
- sharp image of the objective by the bright lens
- cross-hairs: lens can be adjusted to your own eyesight
- Safe Transport by locking device for the compensator
- Robust design with built-in target collimator and integrated in the device box level.
Scope of delivery
- Lens protection
- plumb-line
- Allen key
- Case.
Hints
This text is machine translated.
