Built-in plug USB-A DIP Plug, mount US1AF 1 Port US1AF econ connect Content: 1 pc(s)

A silver USB plug, rectangular and flat, with four contacts on top, for data transfer and powering devices.
Technical drawings of a switch with various views and dimensions; shows height, width, and position of the connections.
1/2
Image similar
Connector type
Plug, mount
Connector standard
USB 2.0
Type
US1AF
Pins
4
Type
1 Port
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
582 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Minimum order quantity: 5
Total (€ 0.55 / piece)
€ 2.75
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Built-in plug USB-A DIP

Our service for you

Technical specifications

Type

US1AF

Connector type

Plug, mount

Pins

4

Type

1 Port

Connector standard

USB 2.0

Connection

Solder pins

Case material

Metal

Manufacturer part #

US1AF

Factory colour

White

Content

1 pc(s)

Contact material

Copper alloy gold plated

Material (details)

PBT

Nominal voltage (details)

30 V

Nominal current (details)

1 A

RoHS-compliant

Yes

Temperature range

-55 - +105 °C

Documents & Downloads

Datasheet

Datasheet 1311464 Built-in plug USB-A DIP Plug, mount US1AF 1 Port US1AF econ connect Content: 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1311464 Built-in plug USB-A DIP Plug, mount US1AF 1 Port US1AF econ connect Content: 1 pc(s)
