Dehner Elektronik CT-251 CT-251 Controller board 1 pc(s)
EAN:
Part number:
Item no:
Number
Total (€ 53.99 / piece)
€ 53.99
incl. VAT
Only 3 Piece(s) available
Highlights & Details
Dehner electronic controller board CT-251 for Cotek AE/AEK series
- Enables: Control of output voltage in a range of 0-105%, and/or output current of 0-105% of the AEK/AE Cotek series via RS232 or RS485 in parallel operation
Technical specifications
- Product type
Controller board
- Compatible with
Cotek
- Weight
53 g
- Compatible with
Cotek AEK Series
Cotek AE Series
- Width
48 mm
- Height
14 mm
- Length
71 mm
- Type
CT-251
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1991953 Dehner Elektronik CT-251 CT-251 Controller board 1 pc(s)
Warranty Terms
Warranty Terms 1991953 Dehner Elektronik CT-251 CT-251 Controller board 1 pc(s)
Description
Control board CT-251 is used as master for control in parallel operation (current modulation).
The board has a RS232 or COM port (CN3), a RS485 port
For controlling further power supplies with CT-551 and a connection plug (CN1) to the power supply.
A maximum of 8 power supplies can be controlled for parallel operation. (1 Master CT-251 and 7 Slaves CT-551 - Conrad Item No. 1991946)
This article consists of – Control Board CT-251 and the connecting cable (COTEK Part no. 47-0124-0001)
Enables: Control of the output voltage in a range of 0-105%, as well as the output current of 0-105%
The following additional components are required to control the power supplies:
- Power supply COTEK AE / AEK - Series
- Control board CT-551 for each additional power supply (slave)
- PC or laptop with existing COM port/RS232, USB-to-RS232 adapter or USB-to-RS485 adapter
- null modem cable
This text is machine translated.
The board has a RS232 or COM port (CN3), a RS485 port
For controlling further power supplies with CT-551 and a connection plug (CN1) to the power supply.
A maximum of 8 power supplies can be controlled for parallel operation. (1 Master CT-251 and 7 Slaves CT-551 - Conrad Item No. 1991946)
This article consists of – Control Board CT-251 and the connecting cable (COTEK Part no. 47-0124-0001)
Enables: Control of the output voltage in a range of 0-105%, as well as the output current of 0-105%
The following additional components are required to control the power supplies:
- Power supply COTEK AE / AEK - Series
- Control board CT-551 for each additional power supply (slave)
- PC or laptop with existing COM port/RS232, USB-to-RS232 adapter or USB-to-RS485 adapter
- null modem cable
This text is machine translated.
Scope of delivery
- Control board
- Connecting cable
