Diotec KBPC801 Diode bridge KBPC8-PB10 100 V 4 A
EAN:
Part number:
Item no:
Product type
Diode bridge
Enclosure
KBPC8-PB10
U(RRM)
100 V
Forward current I(F)
4 A
Forward voltage U(F)
1.20 V
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
2
-
€ 0.87891
6
8% = € 0.07
€ 0.80816
10
11% = € 0.10
€ 0.77986
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 2
Total (€ 0.87891 / piece)
€ 1.76
plus VAT.
14-day return policy included
Technical specifications
- Type wire-leadHousing KBPC8-PB10Periodic Peak Reverse Voltage - VRRM 100 VContinuous current - IFAV 8.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: NsSurge current - IFSM 135.00 AForward voltage - VF 1.20 VIF 4.00 AReverse current - IR 5,000 µAVR 100 VLock layer capacity - CJ: PFVR V
- Type
KBPC801
- Product type
Diode bridge
- Enclosure
KBPC8-PB10
- Manufacturer
Diotec
- Manuf. code
DIO
- U(RRM)
100 V
- Forward current I(F)
4 A
- Forward voltage U(F)
1.20 V
- Forward voltage reference
4.00 A
- I(FSM) 50Hz
135 A
- Reverse leakage current I(r)
5 µA
- Reverse leakage current I(r) reference
100 V
- Operating temperature (max.)
150 °C
- Mounting type
Through-hole mounting
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2809875 Diotec KBPC801 Diode bridge KBPC8-PB10 100 V 4 A
User & Safety Instructions
User & Safety Instructions 2809875 Diotec KBPC801 Diode bridge KBPC8-PB10 100 V 4 A
Description
Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
