Two diodes, pointing in opposite directions. They have black casings with silver stripes and long metal terminals.

Two diodes, pointing in opposite directions. They have black casings with silver stripes and long metal terminals.

Image similar

Diotec

Product type

Rectifier

Enclosure

DO 201

Forward current I(F)

3 A

Reverse voltage U(R)

200 V

Forward voltage U(F)

1 V

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Mon 9 Nov

1479 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 20

Total (€ 0.1164 / piece)

€ 0.12

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Type AxialDO-201 housingPeriodic Peak Reverse Voltage - VRRM 200 VContinuous current - IFAV 3.00 AJunction temperature - Tjmax 175 °CReverse delay time - trr: 50 nsSurge current - IFSM 100.00 AForward voltage - VF 1.00 VIF 3.00 AReverse current - IR 5,000 µAVR 200 VLock layer capacity - CJ: PFVR V

Type: UF5402

Product type: Rectifier

Enclosure: DO 201

Manufacturer: Diotec

Forward current I(F): 3 A

Reverse voltage U(R): 200 V

Forward voltage U(F): 1 V

Reverse leakage current I(r): 5 µA

Operating temperature (max.): 175 °C

Mounting type: Through-hole mounting

I(FSM) 50Hz: 100 A

Reverse recovery time T(rr): 50 ns

RoHS-compliant: Yes

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2808841 Diotec Rectifier UF5402 DO 201 200 V 3 A

User & Safety Instructions

User & Safety Instructions 2808841 Diotec Rectifier UF5402 DO 201 200 V 3 A
