Name: e-ast Inverter HPL 1200-D-12 1200 W 12 V DC - 230 V AC, 5 V DC
Brand: e-ast
SKU: 512970
Availability: InStock

Highlights & Details

e-ast Inverter HPL 1200-D-12 1200 W 12 V DC - 230 V AC, 5 V DC

Produces near sine wave AC power to run regular mains appliances
1200W continuous output, 2400W peak output
Protection against deep discharge, overvoltage, overload, short circuit and overheating

Technical specifications

Input voltage: 12Vdc (11-15V)

Product type: Inverter

Signal output type: Modified sine wave

Output voltage: 230 V AC
5 V DC

: 1200 W

Input voltage: 12 V DC

Inputs: Screw terminals

Output: PG socket
USB

Nominal load efficiency: 90 %

Outlets: 2

Output frequency: 50 Hz

Permanent current: 116 A

Input current (max.): 128 A

Remote control: No

Weight: 3.4 kg

Cooling method: Fan

Width: 330 mm

Height: 80 mm

Length: 200 mm

Peak output power: 2400 W

Type: HPL 1200-D-12

Type: Modified Sine Wave

: 1200 W

Signal output type: Modified sine wave

Output voltage: 230 V/AC · 5 V/DC USB

Cooling: Fans

Output rating: 1200 W

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 512970 e-ast Inverter HPL 1200-D-12 1200 W 12 V DC - 230 V AC, 5 V DC

Information

Information 512970 e-ast Inverter HPL 1200-D-12 1200 W 12 V DC - 230 V AC, 5 V DC

Description

The HPL 1200-D-12 inverter from e-ast's HighPower Line series of modified sine wave inverters produces a modified sine wave AC voltage that is suitable for powering regular 230V-240V mains appliances up to 1200W from a 12Vdc (11-15V) input, such as a solar battery. A connection cable for securely fitting to battery screw terminal is provided with the inverter. The HPL 1200-D-12 can achieve a 2400W peak output for 0.3-0.5 secs.

To avoid damaging batteries through deep discharge, the HPL 1200-D-12 inverter has a protective function that cuts its output when the input voltage drops below its lower voltage range.

Features

Red and green status LEDs
Deep discharge protection
Overvoltage cutout protection
Overload and short-circuit protection with automatic restart
Overheating protection.

Scope of delivery

Modified sine wave inverter
Secure battery connection cable
User manual.

Description

The HPL 1200-D-12 inverter from e-ast's HighPower Line series of modified sine wave inverters produces a modified sine wave AC voltage that is suitable for powering regular 230V-240V mains appliances up to 1200W from a 12Vdc (11-15V) input, such as a solar battery. A connection cable for securely fitting to battery screw terminal is provided with the inverter. The HPL 1200-D-12 can achieve a 2400W peak output for 0.3-0.5 secs.

To avoid damaging batteries through deep discharge, the HPL 1200-D-12 inverter has a protective function that cuts its output when the input voltage drops below its lower voltage range.
