A cylindrical, metallic valve with a long orange lever. It is used for industrial applications.

A cylindrical, metallic valve with a long orange lever. It is used for industrial applications.

Packaging type

Single

Product type

Pressure sensor

Connector

M12

Model

Absolute pressure

Pressure reading range (max.)

16 bar

Endress+Hauser

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 395.00 / piece)

€ 395.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Absolute and relative pressure sensor Cerabar PMP23-AA1M1QB3CJ 4-20 mA connector M12, IP65/67 NEMA type 4X Encl.

Output type: Analogue output
ABS/Gauge pressure: Pressure gauge
M12 plug
Hygienic approval 3 A
Output 4-20 mA
Electrical connection: Connector M12, IP65/67 NEMA type 4X Encl.
Sensor range: 16bar/1.6MPa/240psi pressure gauge, overload: 64bar/6.4MPa/960psi
Calibration Unit: Sensor range mbar/bar
Process connection: Tri-Clamp ISO2852 DN25-38 (1-1/2") DIN32676 DN25-38, EHEDG, 3A

Technical specifications

Process temperature: +135 °C for 1 hour

Packaging type: Single

Product type: Pressure sensor

Type: PMP23

Connector: M12

Model: Absolute pressure

Outputs: Analogue

Output signal (min.): 4 mA

Output signal (max.): 20 mA

Interfaces: IO-Link

Accuracy: 0.3 %

Pressure reading range (min.): -1 bar

Pressure reading range (max.): 16 bar

Pressure reading range: -1 bar up to 16 bar

Contact type: Analogue

: IP65/67

Min. temperature: -10 °C

Max. temperature: +100 °C

RoHS-compliant: Yes

Content: 1 pc(s)

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2886263 Endress+Hauser PMP23-AA1M1QB3CJ Pressure sensor 1 pc(s) -1 bar up to 16 bar M12 Analogue Single

User & Safety Instructions 2886263 Endress+Hauser PMP23-AA1M1QB3CJ Pressure sensor 1 pc(s) -1 bar up to 16 bar M12 Analogue Single

Description

The Cerabar PMP23 is a very compact pressure transmitter for measuring absolute and overpressure in gases, vapors, liquids and dust for applications with hygienic requirements. The PMP23 offers various EHEDG and 3 A certified hygienic process connections, FDA compliant materials, EG1935/2004 compliance, IP69 degree of protection, optional IO-Link and Ex certificates. The device can be supplied with customer-specific measuring ranges up to 40 bar.

This text is machine translated.

Features

Easy to use
High performance
Long-term stability
High material quality

Description

The Cerabar PMP23 is a very compact pressure transmitter for measuring absolute and overpressure in gases, vapors, liquids and dust for applications with hygienic requirements. The PMP23 offers various EHEDG and 3 A certified hygienic process connections, FDA compliant materials, EG1935/2004 compliance, IP69 degree of protection, optional IO-Link and Ex certificates. The device can be supplied with customer-specific measuring ranges up to 40 bar.

This text is machine translated.

Features

Easy to use
High performance
Long-term stability
High material quality
