Name: Fein ASCM 18-4 QM AS METAL ADVANCED SET 71161564000 Cordless drill 18 V
Brand: Fein
SKU: 3323875
Availability: BackOrder

Cordless drill in orange with a black handle, shown from the side.

'Compatible with AMPShare/Bosch Professional 18 V batteries.' Reference to Bosch trademark and batteries, supports multilingual use.

A construction worker kneels on a metal roof and drills with an electric tool, wearing protective clothing and a hard hat, with a city view in the background.

A construction worker wearing a hard hat and safety glasses is drilling a hole in a metal beam on a building site.

1/5

EAN:

Part number:

Item no:

Dispatches on Tue 10 Nov

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 675.00 / piece)

€ 675.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

ASCM 18-4 QM AS Metal Advanced Set

18 V/ battery
Torque (max.) (details) 130 Nm
Torque levels 15 + 1

Technical specifications

Battery voltage: 18 V
Battery compatibility: Li-Ion / ProCORE Li-Ion
Battery interface 18 V AMPShare
Motor: Brushless
Idling speed 430 / 850 / 2000 / 4000
Drill-Ø Wood: 60 mm
Weight without rechargeable battery: 1.30 kg
4 gear
Accessories interface: QuickIN
Max. Torque (hard/soft) 130 (70 / 50) Nm
15 + 1 torque control
Drill chuck range 1.5 - 13 mm
Screws 10 x 400 mm
Tap holes M 14
Drill-Ø Steel Spiral drill 13 mm
Drill-Ø Steel Core driller: 30 mm
Drill-Ø Steel Hole saws: 80 mm

Product type: Cordless drill

Voltage: 18 V

Idle speed (details): 430 / 850 / 2000 / 4000 U/min

Max. torque: 130 Nm

Torque levels: 15 + 1

Max. drill diameter: 1.5 - 13 mm

Transmission type: 4-speed

Weight: 1.30 kg

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3323875 Fein ASCM 18-4 QM AS METAL ADVANCED SET 71161564000 Cordless drill 18 V

Description

4-speed battery-operated drill/screwdriver in user set|ASCM 18-4 QM AS Metal Advanced Set|The all-rounder ASCM 18-4 QM AS with 8-piece bit set, QuickIN bit holder 7/4", QuickIN threaded drill clamps 6 mm and 6 mm, HSS cobalt 5% spiral drill set 4.5-piece and HSS thread-tap set 1-piece.

This text is machine translated.

Features

4-speed full metal gear With speeds up to 4000 rpm for optimum cutting speeds in metal for each hole from 1.5 to 80 mm.
The largest possible application with the FEIN QuickIN-system for multi-functional use around drilling, core-drilling, thread-drilling, sinks and screws.
Quick-release, tool-free replacement of the QuickIN attachments between the applications in metal and wood with just one machine.
Very safe working. Kickback monitoring stops the machine.
More control through removable additional handle.
The brushless, powerful FEIN PowerDrive motor, with up to 30% higher efficiency, enables a higher life span.
High torque up to a maximum of 130 Nm.
QuickIN full metal drill chuck (120 Nm) with carbide-tipped clamping jaws and high clamping forces.
Electronic torque setting (15+1).
Intuitive control panel with dimmable LED for perfect lighting of the working place depending upon the material.
Ergonomic and flexible use with side-mounted bit and belt holder.
8-piece bit set. Bit holder and 7 bits (PZ2, PZ3, T15, T20, T25, T30, T40, 60-1/4).
HSS cobalt 5% spiral drill set, 6-piece (2 mm, 3 mm, 4 mm, 5 mm, 6 mm, 8 mm).
HSS tap set 7-piece (M3, M4, M5, M6, M8, M10, M12).
QuickIN bit holder, QuickIN threaded drill chucks 4.5 mm and 6 mm.
Screwed 10 x 400 mm screws without pre-drilling.
AMPShare interface enables 1 400 screws (5 x 40 mm in wood) per battery charge (ProCORE 4 Ah).
Extensive user protection through restart protection, electronic overload protection and brake.
The innovative reset function allows wood screws to be tightened at reduced speed for perfect results.
Compatible with Bosch Professional 18 V batteries since 2008 and AMPShare batteries.
Maximum work progress with AMPShare 18 V ProCORE batteries: COOLPACK 2.0 technology provides a 135% longer battery life. The latest cell technology and intelligent battery management ensure 87% more power than conventional batteries. Electronic Cell Protection (ECP) protects the battery against overload, overheating and total discharge
Best equipped for every use. Mobile working with the L-BOXX system.

Scope of delivery

1 ASCM 18-4 QM AS (incl. handle, belt clip, bit holder)
1 8-piece bit set
1 QuickIN Bit holder
1 QuickIN threaded-drill chuck 4.5 mm
1 QuickIN threaded-drill chuck 6 mm
1 HSS cobalt 5% spiral drill set, 6 piece
1 HSS tap drill set, 7-piece
1 plastic tool case (L-BOXX 136)
