Name: Fein ASCM 18-4 QM AS QUICKIN SET 71161566000 Cordless drill 18 V Li-ion brushless
Brand: Fein
SKU: 3323877
Availability: InStock

Cordless drill with multiple attachments and carrying case. Ideal for versatile screwing and drilling applications.

Battery Drill Hammer: An orange and black cordless drill hammer with an ergonomic handle. Ideal for powerful drilling in concrete and masonry.

Compatible with AMPShare/Bosch Professional 18 V batteries.

A construction worker wearing an orange hard hat is securing a screw on a metal roof using a cordless drill.

A worker wearing safety glasses and ear defenders is drilling a metal beam of a building, wearing an orange hard hat and black and grey workwear.

1/5

Datasheet (PDF)

Fast track dispatch on Thu 15 Oct

1 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 815.00 / piece)

€ 815.00

incl. VAT

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Fein ASCM 18-4 QM AS QUICKIN SET 71161566000 Cordless drill 18 V Li-ion brushless

18 V/ Li-ion battery
Torque (max.) (details) 130 Nm
Screw Ø (max.) (details) 10 x 400 mm
Torque levels 15 + 1

Technical specifications

Battery voltage: 18 V
Battery compatibility: Li-Ion / ProCORE Li-Ion
Battery interface 18 V AMPShare
Motor: Brushless
Idling speed 430 / 850 / 2000 / 4000
Drill-Ø Wood: 60 mm
Weight without rechargeable battery: 1.30 kg
4 gear
Accessories interface: QuickIN
Max. Torque (hard/soft) 130 (70 / 50) Nm
15 + 1 torque control
Drill chuck range 1.5 - 13 mm
Screws 10 x 400 mm
Tap holes M 14
Drill-Ø Steel Spiral drill 13 mm
Drill-Ø Steel Core driller: 30 mm
Drill-Ø Steel Hole saws: 80 mm

Product type: Cordless drill

Voltage: 18 V

Technology: Li-ion

Idle speed (details): 430 / 850 / 2000 / 4000 U/min

Max. torque: 130 Nm

Torque levels: 15 + 1

Max. screw Ø: 10 x 400 mm

Max. drill diameter: 1.5 - 13 mm

Features: brushless

Transmission type: 4-speed

Weight: 1.30 kg

Weight, information: without rechargeable battery

Documents & Downloads

Datasheet

Datasheet 3323877 Fein ASCM 18-4 QM AS QUICKIN SET 71161566000 Cordless drill 18 V Li-ion brushless

User & Safety Instructions

User & Safety Instructions 3323877 Fein ASCM 18-4 QM AS QUICKIN SET 71161566000 Cordless drill 18 V Li-ion brushless

Description

4-speed battery-powered drill/screwdriver in user set|ASCM 18-4 QM AS QuickIN Set|The all-rounder ASCM 18-4 QM AS with 7 QuickIN quick-change attachments for maximum efficiency and a variety of applications for drilling, tapping and screwing. Everything is clearly, neatly and securely stored in the i-BOXX.

This text is machine translated.

Features

4-speed full metal gear With speeds up to 4000 rpm for optimum cutting speeds in metal for each hole from 1.5 to 80 mm.
The largest possible application with the FEIN QuickIN-system for multi-functional use around drilling, core-drilling, thread-drilling, sinks and screws.
Quick-release, tool-free replacement of the QuickIN attachments between the applications in metal and wood with just one machine.
Very safe working. Kickback monitoring stops the machine.
More control through removable additional handle.
The brushless, powerful FEIN PowerDrive motor, with up to 30% higher efficiency, enables a higher life span.
High torque up to a maximum of 130 Nm.
QuickIN full metal drill chuck (120 Nm) with carbide-tipped clamping jaws and high clamping forces.
Electronic torque setting (15+1).
Intuitive control panel with dimmable LED for perfect lighting of the working place depending upon the material.
Ergonomic and flexible use with side-mounted bit and belt holder.
QuickIN accessories set in the i-BOXX comprising of 7 QuickIN accessories: 1 bit holder 1/4", 1 socket adapter 1/2", 1 threaded-drill attachment, threaded-drill chucks 1 x 4.5 mm, 1 x 6 mm, 1 eccentric attachment, 1 angular head. The i-BOXX case insert also offers space for other QuickIN accessories.
Screwed 10 x 400 mm screws without pre-drilling.
AMPShare interface enables 1 400 screws (5 x 40 mm in wood) per battery charge (ProCORE 4 Ah).
Extensive user protection through restart protection, electronic overload protection and brake.
The innovative reset function allows wood screws to be tightened at reduced speed for perfect results.
Compatible with Bosch Professional 18 V batteries since 2008 and AMPShare batteries.
Maximum work progress with AMPShare 18 V ProCORE batteries: COOLPACK 2.0 technology provides a 135% longer battery life. The latest cell technology and intelligent battery management ensure 87% more power than conventional batteries. Electronic Cell Protection (ECP) protects the battery against overload, overheating and total discharge
Best equipped for every use. Mobile working with the L-BOXX system.

Scope of delivery

1 ASCM 18-4 QM AS (incl. handle, belt clip, bit holder)
1 QuickIN accessories set, 7 pieces
1 plastic tool case (L-BOXX 136)
1 i-BOXX
1 i-BOXX rack
