Name: FESTO Air gap sensor 1 pc(s) SOPA-CM4H-R1-HQ6-2N-M12 M12 plug (5-pin)
Brand: FESTO
SKU: 2204450
Availability: BackOrder

An electrical distribution module with multiple terminals and connectors, suitable for industrial applications.

Image similar

Product type

Air gap sensor

Connector

M12 plug (5-pin)

Max. operating voltage

26.4 V DC

Type

SOPA-CM4H-R1-HQ6-2N-M12

Output signal (max.)

100 mA

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 2,085.00 / piece)

€ 2,085.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Air gap sensor

Technical specifications

Display type: Light-LCD multi-color
Fastening method: Optional:
With through hole
With DIN rail
With wall/surface holder
Operating pressure: 4 ... 7 bar
Operating medium: Compressed air according to ISO 8573-1:2010 [7:4:4]
Operating voltage range DC: 22.8 ... 26.4 V
CE mark (see declaration of conformity): According to EU EMC directive
According to EU-RoHS-RL
Setting options: Teach-in
Via display and buttons
Electrical connection: Connector
Round design
According to EN 60947-5-2
M12x1
5-pin
Detection range: 20 ... 200 µm
Note on operating and control medium: Oiled operation possible (required in further operation)
KC-MARK: KC-EMC
Short-circuit resistance: Isochronous
Tamper protection: Electronic locking
Max. output current 100 mA
Measuring principle: Pneumatic
Pneumatic connection: QS-6
Product weight: 695 g
IP65 rating
According to IEC 60529
Ambient temperature: 0 ... 50 °C
Reverse polarity protection: For all electrical connections
Material housing: PA-reinforced
Material information: Free of copper and PTFE
Complies with RoHS
Repeat accuracy switching point: ±2.5 µm detection range 30 µm to 150 µm
±5 µm detection range 20 to 200µm
Approval: RCM Mark
C UL us - Recognized (OL)

Product type: Air gap sensor

Type: SOPA-CM4H-R1-HQ6-2N-M12

Connector: M12 plug (5-pin)

Output signal (max.): 100 mA

Interfaces: M12 plug

Min. operating voltage: 22.8 V DC

Max. operating voltage: 26.4 V DC

Operating voltage: 22.8 - 26.4 V DC

Operating current: 100 mA

: IP65

Min. temperature: 0 °C

Max. temperature: +50 °C

Weight: 690 g

Content: 1 pc(s)
