FESTO Proportional pressure regulator 572410 VPPM-8TA-L-1-F-0L2H-C1 Connector plate Nominal width (details) 7 mm Enclosu
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 1,075.00 / piece)
€ 1,075.00
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
Proportional pressure regulator VPPM-8TA-L-1-F-0L2H-C1
Technical specifications
- Operating medium
According to ISO 8573-1:2010 compressed air [7:4:4],, inert gases
- Product type
Proportional pressure regulator
- Operating voltage
26.4 V
- Enclosure material
Aluminium wrought alloy
- Connection
Connector plate
- Max. flow
450 l/min
- Operation
Electrically
- Type
Electrical connection: via connection plate
- Manufacturer part #
572410
- Function
3-way
- Weight
560 g
- Media temperature (range)
10 up to 50 °C
- Max. media temperature
50 °C
- Media temperature (min.)
10 °C
- Nominal width
7 mm
IP65
- Control pressure (max.)
2 bar
- Control pressure (min.)
0.02 bar
- Max. ambient temperature
50 °C
- Min. ambient temperature
0 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1944481 FESTO Proportional pressure regulator 572410 VPPM-8TA-L-1-F-0L2H-C1 Connector plate Nominal width (details) 7 mm Enclosu
User & Safety Instructions
User & Safety Instructions 1944481 FESTO Proportional pressure regulator 572410 VPPM-8TA-L-1-F-0L2H-C1 Connector plate Nominal width (details) 7 mm Enclosu
Description
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
