Finder SSR 39.40.8.230.9024 2 A Switching voltage (max.): 24 V DC 1 pc(s)

Blue Finder Relay, MasterINPUT model, shows technical data and connections for various voltages and contact settings.
'Circuit diagram shows AC and DC SSR outputs. On the left, AC SSR, on the right DC SSR with protective and indicator circuitry. Various symbols depicted.'
Building plan shows the floor layouts and dimensions of a multi-room building. Measurements are given in centimetres.
1/3
Image similar
Packaging type
Piece
Product type
SSR
Control voltage (max.)
230 V AC
Switching voltage (max.)
24 V DC
Current load (max.)
2 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Available soon
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Minimum order quantity: 10
Multiple: 10
Total (€ 32.99 / piece)
€ 329.90
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

MasterINPUT coupling relay 39.40 (SSR)

  • 'UL' Mark: A test mark in a circle with the letters 'c' on the left and 'us' on the right. Stands for safety certification.

Technical specifications

Packaging type

Piece

Product type

SSR

Type

39.40.8.230.9024

Connection

Screw terminal

Control voltage (max.)

230 V AC

Control voltage range

230 V AC (max)

Switching voltage (min.)

1.5 V DC

Switching voltage (max.)

24 V DC

Current load (max.)

2 A

Output voltage (min.)

1.5 V DC

Output voltage (max.)

33 V DC

Max. output current

6 A

Contact type

1 maker

Permanent current (max.)

6 A

Content

1 pc(s)

Nominal control voltage

230 V AC

Nominal voltage (details)

230 V AC

Type

39.40.8.230.9024

TRUE

Documents & Downloads

Datasheet

Datasheet 506913 Finder SSR 39.40.8.230.9024 2 A Switching voltage (max.): 24 V DC 1 pc(s)

User & Safety Instructions

User & Safety Instructions 506913 Finder SSR 39.40.8.230.9024 2 A Switching voltage (max.): 24 V DC 1 pc(s)

Description

Sleek interface relay for DIN rail with semiconductor output. For correct connection of actuators to PLC outputs. Actuator connections on same coupling relay output with simple cable assignment.

This text is machine translated.

Hints

Approvals: cULus
