Fluke FLUKE 1663 DE KIT Electrical tester set
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 1,730.25 / piece)
€ 1,730.25
plus VAT.
Only 4 Piece(s) available
Technical specifications
- AC voltage 500 V.Resolution 0.1 VInput impedance 360 kΩOverload protection 660 V effectiveMEASUREMENT RANGE 20 Ω/200 Ω/2000 ΩTest voltages 50/100/250/500/1,000 V.
- Product type
Electrical tester set
Manufacturer's standards (no certificate)
- Reading category
CAT III 500 V
CAT IV 300 V
- Dim
(L x W x H) 100 x 250 x 125 mm
- Weight
1.3 kg
IP40
- Reading range (VDE)
Voltage
Frequency
Insulation resistance
Loop impedance
Resistance
- DIN standard
DIN EN 61010-1
- Display type
Digital (LCD)
- Accuracy
0.8 %
- Width
250 mm
- Height
125 mm
- Length
100 mm
- Voltage supply
Battery
- Memory
Yes
- Type
FLUKE 1663 DE KIT
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2576810 Fluke FLUKE 1663 DE KIT Electrical tester set
User & Safety Instructions
User & Safety Instructions 2576810 Fluke FLUKE 1663 DE KIT Electrical tester set
Information
Information 2576810 Fluke FLUKE 1663 DE KIT Electrical tester set
Description
Fluke 1663 DE multifunction tester, meets all local regulations, now bundled with Fluke TruTest™ data management and reporting software. Fluke TruTest software simplifies data management and reporting for instrument testing over traditional procedures. Whether you are testing equipment in an office, verifying repairs in a workshop, or conducting annual visual inspections, proper data management is critical to creating easy-to-understand reports for customers. The TruTest software enables quick and easy import of measurement results directly from test devices, management of files transferred from devices, and manual input of data as required.
This text is machine translated.
This text is machine translated.
Features
- Measurement functionsContinuity at inputs L-N, N-PEChecking DC-sensitive RCD/FIS (type B)Earthing resistanceVoltage and frequencyPolarity tester, detects interrupted N-conductorsInsulating resistanceContinuity and resistanceMeasure motor windings with continuity testLoop and mains impedanceExpected ground fault current (PEFC/IK)Expected short circuit current (PSC/IK)RCD tripping timeRCD tripping current (ramp test)Measures trip time and trip current for RCD type A and AC in a single testVariable test current for RCDsAutomatic test sequence for residual current protective devices (RCDs)Rotary field indicator;Additional functions:Automatic start can be switched on and off for RCD and loop impedance measurementSelf-testBacklit display
Scope of delivery
- Multifunction installation tester 16636 AA-batteriesC1600 hard shell caseZero adaptersRobust mains measuring leadTest lead setPadded carrying and hip beltQuick guideTP165X probe with release button and test leadsIR189 USB cableTruTest data management software
