Name: Gedore 1640720 Workshop trolley
Brand: Gedore
SKU: 1909543
Availability: BackOrder

Blue, enclosed goods wagon with four wheels and a side handrail.

EAN:

Part number:

Item no:

Dispatches on Tue 15 Dec

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1,545.00 / piece)

€ 1,599.00

€ 1,545.00

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Sheet steel, corrosion-resistant and scratch-resistant powder-coated, GEDORE blue
Body:
Dimensions: H985 x W 775 x T 475 mm
Shelf made of ABS plastic with 3 small pockets, 2 boxes trays, 8 screwdrivers dashboard
Storage space with perforated plate lining (PERFORATION 10 x 38 mm) and 2 removable small drawers and doors on the handle side
Flexible and easy to control by driving Steering Handle
Front face side with perforation 10 x 38 mm for fixing of hooks and tools
Security through the heel impact protection for persons and environment protection and edges
Drawers:
Central locking with cylinder lock
Width drawers (B480 x T400 mm) with full extension, removable
Safety lock per drawer and storage compartment, single-handed operation
Ball-bearing guide rails
Individual configuration by longitudinal and cross dividers (also available individually)
Load capacity per drawer 40 kg, lower heavy load tray 60 kg (not with no. 2004 1000)
GEDORE high-performance chassis:
Total load capacity 500 kg
2 rollers GEDORE high-performance wheels (rollers diameter 200 mm)
2 ball-bearing GEDORE smooth running wheels (steering wheels Ø 125 mm), both with total locking device
GEDORE axle construction provides even at maximum load: smooth running, agility, and track
Accessories:
Length-wise (LT) and cross dividers (QT) made of galvanised steel sheet (also available individually)
Options:
Optimally can be fitted by GEDORE tool modules (No. 1500 ES/1500 CT)
Can be expanded by GEDORE attachment chests, rear walls and tool holder
Other drawers variants on request
Special colors and designs on request
Supplied without tools and accessories

Product type: Workshop trolley

Dim: (W x H) 775 mm x 985 mm

No. of drawers: 8

Weight: 88 kg

Content: 1 pc(s)

Width: 775 mm

Height: 985 mm

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1909543 Gedore 1640720 Workshop trolley

Information

Information 1909543 Gedore 1640720 Workshop trolley

Features

Body:
Dimensions: H 985 x W 775 x D 475 mm
Working platform in ABS, with 3 compartments for small parts
Storage compartment with perforated sheet (Euro perforation 10 x 38 mm), two removable drawers for small parts and door on the handle side
With handle for easy pushing, pulling and turning
Front side with Euro perforation 10 x 38 mm to fix hooks and tools
Heel and impact protection for your safety
Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE blue Drawers:
Central locking with cylinder lock
Wide drawers (W 480 x D 400 mm) fully extendable, removable
Each drawer and storage compartment with safety locking, single-hand operation
Ball-bearing guide rails
Can be individually equipped with lengthwise and crosswise dividers (can be ordered individually)
Load capacity per drawer 40 kg, bottom heavy-duty drawer 60 kg (apart from 2004 1000)
Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE blue GEDORE High-performance chassis:
Total load capacity 500 kg
2 high-performance wheels on roller bearings (fixed castors Ø 200 mm)
2 smooth running wheels on ball bearings (swivel castors Ø 100 mm), both with total brake
The GEDORE axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads Accessories:
Length- (LD) and crosswise (CD) dividers from zinc-plated sheet steel Options:
Can be equipped with GEDORE tool modules (1500 ES/1500 CT)
Optionally extendable with GEDORE tool chests, rear panels and tool holders
Further drawer combinations on request
Special colours and designs available on request
Delivery without tools and accessories

Description

Features

Body:
Dimensions: H 985 x W 775 x D 475 mm
Working platform in ABS, with 3 compartments for small parts
Storage compartment with perforated sheet (Euro perforation 10 x 38 mm), two removable drawers for small parts and door on the handle side
With handle for easy pushing, pulling and turning
Front side with Euro perforation 10 x 38 mm to fix hooks and tools
Heel and impact protection for your safety
Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE blue Drawers:
Central locking with cylinder lock
Wide drawers (W 480 x D 400 mm) fully extendable, removable
Each drawer and storage compartment with safety locking, single-hand operation
Ball-bearing guide rails
Can be individually equipped with lengthwise and crosswise dividers (can be ordered individually)
Load capacity per drawer 40 kg, bottom heavy-duty drawer 60 kg (apart from 2004 1000)
Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE blue GEDORE High-performance chassis:
Total load capacity 500 kg
2 high-performance wheels on roller bearings (fixed castors Ø 200 mm)
2 smooth running wheels on ball bearings (swivel castors Ø 100 mm), both with total brake
The GEDORE axle construction secures smooth running, manoeuvrability and track-keeping also in case of maximum loads Accessories:
Length- (LD) and crosswise (CD) dividers from zinc-plated sheet steel Options:
Can be equipped with GEDORE tool modules (1500 ES/1500 CT)
Optionally extendable with GEDORE tool chests, rear panels and tool holders
Further drawer combinations on request
Special colours and designs available on request
Delivery without tools and accessories
