Greisinger GTH2448/1 LED Digital Thermometer Display -50 to +1150 °C
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 85.99 / piece)
€ 85.99
incl. VAT
Only 7 Piece(s) available
Highlights & Details
Greisinger switch panel mounted thermometer 24 x 48 mm GTH 2448/1
- Supply voltage ranges can be set via solder bridges
- Low installation depth
- Zero-point balancing through spindle trimmer
Technical specifications
- Product type
Digital rack-mount meter
- Reading type
Temperature
- Type
GTH2448/1
- Reading range (max.)
+1150 °C
- Display technology
LED
- Recess width
45 mm
- Recess height
22 mm
- Dim
(W x H x D) 48 x 24 x 65 mm
- Width
48 mm
- Height
24 mm
- Frame width
24 mm
- Interfaces
Screw terminal
- Digit height
10 mm
- Depth
65 mm
- Type
K-type
- Digits
4
- Assembly dimensions
45 x 22 mm
- Accuracy
± 1 %
- Temperature
-50 to +1150 °C
- Sample rate
0.3 s
- Temperature resolution
1 °C
- Operating voltage
8 - 29 V/DC/8 - 27 V AC
Documents & Downloads
Datasheet
Datasheet 121537 Greisinger GTH2448/1 LED Digital Thermometer Display -50 to +1150 °C
User & Safety Instructions
User & Safety Instructions 121537 Greisinger GTH2448/1 LED Digital Thermometer Display -50 to +1150 °C
Description
Affordable 3 1/2-digit low cost LED display from -50 to +1150 °C, for use with NiCr-Ni sensors (type K). This small, thin display is perfect for control panels, vehicles, automotive sports, etc. Installation with spring clips, connection with screw or plug terminal.
Hints
Sensor not included
