Name: HARTING 09185146324 Edge connector (pins) Total number of pins 14 No. of rows 2 1 pc(s)
Brand: HARTING
SKU: 742525
Availability: InStock

Multi-pin connector with a beige plastic housing, commonly used in electronic devices.

Image similar

Product type

Edge connector (pins)

Total no. of pins

Connector type

Multipole connector, straight

2.54 mm

Content

1 pc(s)

Datasheet (PDF)

Fast track dispatch on Thu 15 Oct

70 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 2.49 / piece)

€ 2.49

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

HARTING 09185146324 Edge connector (pins) Total number of pins 14 No. of rows 2 1 pc(s)

No. of rows 2
Content 1 pc(s)

Our service for you

Technical specifications

Product type: Edge connector (pins)

Total no. of pins: 14

Connector type: Multipole connector, straight

Connector orientation: Perpendicular (to the PCB)

No. of rows: 2

CS: 2.54 mm

Nominal current: 2 A

Nominal current - rounded value: 2 A

Pins per row: 7

Connection: Print

Factory colour: Grey

Case material: PA

Manufacturer part #: 09185146324

Content: 1 pc(s)

Contact material: Copper alloy

Width: 25.6 mm

Height: 12.35 mm

Length: 9.3 mm

Max. temperature: +125 °C

Min. temperature: -55 °C

Type: 09 18 514 6324

Dim: (L x W x H) 9.3 x 25.6 x 12.35 mm

Nominal voltage: 500 V

Certification marks: IEC 60603-13

Number of pins: 14

RoHS-compliant: Yes

Pin length: 2,9 mm

Contact surface: Gold plated

Material (details): PBTB to UL 94VO standard

Connection: -
