HiFiBerry Mini AMP HiFiBerry sound card Compatible with (development kits): Raspberry Pi® Zero

The HiFiBerry MiniAmp is a very small but very efficient Class D amplifier for the Raspberry Pi Zero. (Also works with all newer models with 40-pin GPIO connector.) Speakers are simply connected directly to the board; i.e. this is the ideal module for simple projects, when the power of the Amp+ is not needed.

Technical characteristics:
• up to 2 x 3 W output power
• suitable for a pair of loudspeakers with 4 - 8 ohms
• Sample rates 44.1 kHz - 192 kHz
• Digital-to-analogue conversion is integrated; external converters or sound cards are not required
• can be connected directly to the Raspberry Pi; no additional cables are required
• Power comes directly from the Raspberry Pi; no major power supply required
It • delivered as a ready-made kit, simply connect it to the Raspberry Pi! On Raspberry Pi Zero, the GPIO pin strip must be soldered on.
• low-interference voltage regulator for optimal audio performance
• without mounting material (i.e. spacer, 40-pin strip for Raspberry Pi Zero)
• Without hardware-based volume control – but most programs include volume control

This text is machine translated.
