HKE CMA31-DC24V-C Automotive relay 24 V DC 30 A 1 change-over
EAN:
Part number:
Item no:
Product type
Automotive relay
Coil nominal voltage
24 V DC
Contact type
1 change-over
Connection
Type C CEE 7/16 plug 6.3 mm
Switching voltage (max.)
14 V DC
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.03
5
7% = € 0.27
€ 3.76
10
9% = € 0.37
€ 3.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.03 / piece)
€ 4.03
plus VAT.
Highlights & Details
Automotive relay, series CMA 31
Our service for you
Technical specifications
- Product type
Automotive relay
- Type
CMA31-DC24V-C
- Features
+ L-mount
- Coil nominal voltage
24 V DC
- Min. pick-up voltage
16.8 V DC
- Contact type
1 change-over
- Connection
Type C CEE 7/16 plug 6.3 mm
- Switching voltage (max.)
14 V DC
- Switching current (max.)
30 A
- Max. switching capacity
420 W
- Resistance (coil)
360 Ω
- Durability
1000 0000 switching cycles
- Electrical lifespan
100 000 Switching cycles
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Width
27.8 mm
- Height
50.1 mm
- Length
30.8 mm
- Dim
(L x W x H) 30.8 x 27.8 x 50.1 mm
- RoHS-compliant
Yes
- Type
CMA 31-DC24V-C
Documents & Downloads
Datasheet
Datasheet 1366565 HKE CMA31-DC24V-C Automotive relay 24 V DC 30 A 1 change-over
User & Safety Instructions
User & Safety Instructions 1366565 HKE CMA31-DC24V-C Automotive relay 24 V DC 30 A 1 change-over
Description
Automotive relay with spade connectors.
This text is machine translated.
This text is machine translated.
Hints
Switch current information refers to peak current. Full details free to download from our comprehensive product documents library.
