HTB UCFL 210 Flange bearing Grey iron Bore diameter 50 mm Hole spacing 157 mm
EAN:
Part number:
Item no:
Enclosure material
Grey iron
Bore Ø
50 mm
Product type
Flange bearing
Type
UCFL 210
Dim
(A x b x e x i x g x l x s x Z uc x n uc) 197 x 115 x 157 x 22 x 15 x 40 x 19 x 54.6 x 19 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 22.68
3
4% = € 0.98
€ 21.70
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 22.68 / piece)
€ 22.68
plus VAT.
Technical specifications
- Type
UCFL 210
- Dim
(A x b x e x i x g x l x s x Z uc x n uc) 197 x 115 x 157 x 22 x 15 x 40 x 19 x 54.6 x 19 mm
- Weight
2.2 kg
- Width
11.5 cm
- Dimensions
(A x b x e x i x g x l x s x Z uc x n uc) 197 x 115 x 157 x 22 x 15 x 40 x 19 x 54.6 x 19 mm
- Enclosure material
Grey iron
- Bore Ø
50 mm
- Dynamic load rating (radial)
27600 N
- Hole spacing
157 mm
- Radial load rating
20100 N
- Product type
Flange bearing
Documents & Downloads
Datasheet
Datasheet 197089 HTB UCFL 210 Flange bearing Grey iron Bore diameter 50 mm Hole spacing 157 mm
User & Safety Instructions
User & Safety Instructions 197089 HTB UCFL 210 Flange bearing Grey iron Bore diameter 50 mm Hole spacing 157 mm
Description
For simple bearings as e.g. in agricultural machinery, conveyor systems, construction machines The UCFL unit consists of a sealed bearing and a housing of pedestal bearing made of cast iron The attachment of shaft is done by means of stud screws at the inner ring. Misalignments at the shaft can become balanced by the spherical exterior surface of the bearing
Hints
Housing Bearing units have bearing inserts with spherical (balligen) outer ring. The seat is hohlkugelig. Therefore escape housing bearing units, angle errors are balanced.
The bearing in the housing can be up to approx. 4° - 6° in alignment.
The housing bearing is applied at the mounting of the two shaft ends of self-correct polarity. Therefore, it is not necessary that the units in the delivery condition exactly aligned.
