JBL Control 2 PS Active monitor 13 cm 5 inch 35 W 1 Pair
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 174.50 / piece)
€ 349.00
incl. VAT
Only 5 Pair available
Highlights & Details
JBL CONTROL 2 Studio/monitor speakers
- 35 W sine output
- Magnetically shielded
Technical specifications
- Product type
Active monitor
- RMS power
35 W
- Max. power
70 W
- Speaker size (cm)
13 cm
- Speaker size (inch)
5 inch
- Interfaces
Screw terminals
6.3 mm jack in
XLR out
XLR in
6.3 mm jack out
RCA in
- Dim
(W x H x D) 143 x 235 x 159 mm
- Frequency range
80 - 20 K Hz
- Weight
4.8 kg
- Factory colour
Black
- Width
143 mm
- Height
235 mm
- Depth
159 mm
- Max. sound pressure
115 dB
- Max. RMS power
2 x 35/70 W
- Impedance
4 Ω
- SPL
115 dB
Documents & Downloads
Datasheet
Datasheet 304143 JBL Control 2 PS Active monitor 13 cm 5 inch 35 W 1 Pair
User & Safety Instructions
User & Safety Instructions 304143 JBL Control 2 PS Active monitor 13 cm 5 inch 35 W 1 Pair
Description
The control 2PM (master) is a very compactly developed, high-quality active monitor. It is suitable for intercept/hearing control for a very large area of application - in the dome and broadcast studio as well as outside broadcasting vans, for post production of video and PC jobs. The active monitor is an ideal solution also as compact loudspeakers for acoustic radiation and call systems in restaurants, hotels and within the audiovisual range. Possible connections are cinch and XLR/jack combination sockets in each case for the left and the right as well as internal and external loudspeakers. The output of the second amplifier is implemented on 6.3 mm jack socket.
Features
- 13 cm woofer loudspeaker, 19 cm tweeter calotte
- Peak Limiter protects against overload of the system
- Laterally placed loudspeaker potentiometers with headphone output and a switchable high-tone adjustment by ±2 dB
- Volume control
- 3.5 mm stereo-jack headphone output
- Balanced XLR-/jack inputs
- /unbalanced Phono inputs
- Optional wall holder with ball-joint.
Scope of delivery
- Active box/speaker control 2PM, Passive box/speaker control 2 PS (is connected over/via the 2PM).
Hints
2 years warranty.
