LAPP 4726124K Strand X07Z-K 1 x 6 mm² Yellow 400 m
EAN:
Part number:
Item no:
Product type
Strand
No. of leads
1 x
Cross section (each core)
6 mm²
Cable type
X07Z-K
Outside Ø
5.50 mm
Total (1 m = € 1.57)
€ 626.05
plus VAT.
14-day return policy included
Highlights & Details
X07Z-K 90° C
Technical specifications
- Product type
Strand
- No. of leads
1 x
- Content
400 m
- Cross section (each core)
6 mm²
- Insulation material
Polyolefin
- Cable features
Flame-retardant
Halogen-free
Flexible
- Cable type
X07Z-K
- Outside Ø
5.50 mm
- Nominal voltage
750 V
- Packaged
Yes
- Halogen-free
Yes
- Manufacturer part #
4726124K
- Factory colour
Yellow
- Core layout
Finely stranded according to VDE 0295, Class 5/IEC 60228 Class 5
- Sold per metre
No
- Nominal voltage U0
450 V
- Test voltage
2500 V
- Cross section
1 x 6 mm²
- Max. temperature range (flexible installation)
+90 °C
- Min. temperature range (flexible installation)
-15 °C
- Max. temperature range (fixed installation)
+90 °C
- Min. temperature range (fixed installation)
-15 °C
- Type
X07Z-K 90°C EMBOSS 1X6 GN
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1334453 LAPP 4726124K Strand X07Z-K 1 x 6 mm² Yellow 400 m
Description
H07Z-K 90° C-halogen-free single conductor. For use in the control cabinet. For wiring lights, equipment, switchboard and distribution panels. For laying in pipes, on, in and under plaster as well as in closed installation channels
In buildings containing large numbers of people or material assets. For use in dry rooms.
