Name: Laserliner LaserRange-Master Gi4 Mini Laser range finder Rechargeable Li-ion battery 40 m
Brand: Laserliner
SKU: 3758611
Availability: InStock

Laserliner handheld laser distance meter showing a 40.12 m reading on the display, with distance and clear buttons below.

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

3 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 91.99 / piece)

€ 91.99

incl. VAT

Only 3 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Extremely compact laser distance measurer with green laser technology and Pythagoras angle function

Reading range 0.5 m - 40 m
Accuracy ± 2 mm

Technical specifications

Screen technology: LCD

Product type: Laser range finder

Type: laser rangefinder;

Min. reading range: 0.5 m

Max. reading range: 40 m

Accuracy ±: 2 mm

Units of measurement: m

Functions: Alti
Indirect measurement (trigonometric)
Volume calculator
Length measurement
Area calculator

Power supply (details): Li-Ion battery pack 3.7V / 3.0Ah / 11.1 Wh

Weight: 49 g

Weight, information: incl. rechargeable battery

Memory: 19 memory slots

Laser category: 2

Dim: (L x W x H) 20 x 40 x 75 mm

Width: 40 mm

Height: 75 mm

Length: 20 mm

Features: Rechargeable Li-ion battery

Type: LaserRange-Master Gi4 Mini

Rechargeable battery technology: Li-ion

Factory colour: Black
Green

Depth: 20 mm

Type: laser rangefinder;

Battery capacity: 3 Ah

Battery voltage: 3.7 V

UKCA: yes

Operating temperature (T-T): -10 - 40 °C

Accuracy: 2 mm

Maximum measurement distance: 40 m

Minimum measurement distance: 0.05 m

Area measurement: yes

Volume measurement: yes

Min/max measurement: yes

Quantity per pack: 1 Stück(e)

Wavelength: 515 nm

Battery included: yes

Continuous measuring: yes

Rechargeable battery: yes

Memory function: yes

Operating relative humidity (H-H): 20 - 85 %

Battery capacity: 11.1 Wh

Number of memory records: 19

Documents & Downloads

Datasheet

Datasheet 3758611 Laserliner LaserRange-Master Gi4 Mini Laser range finder Rechargeable Li-ion battery 40 m

User & Safety Instructions

User & Safety Instructions 3758611 Laserliner LaserRange-Master Gi4 Mini Laser range finder Rechargeable Li-ion battery 40 m

Description

This laser range finder enables the precise determination of lengths, surfaces and volumes, Ideal for the recording of room sizes and the calculation of material quantities. You can use Pythagoras angle function for indirect determination of height and distance. Green laser technology provides excellent visibility. An easy to read display with clear white digits on a black background, the selectable housing reference point and the extremely compact design make the application comfortable. The powerful lithium-ion battery provides a long operating duration and after short periods of inactivity, the laser and then the device switch off energy-saving.

This text is machine translated.
