Metz Connect 130920-E 24 ports Network patch panel 483 mm (19") CAT 6A 1 U Silver (metallic) Equipped
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 184.87 / piece)
€ 184.87
plus VAT.
Only 7 Piece(s) available
BTR 48.26 cm (19") Patch Panel CAT 6A 1HE unfitted
Highlights & Details
- 48.26 cm (19") 1HE module carrier with/for 24 E-DAT modules
- Integrated cable traps, additional strain-relief possible
- Front of the module carrier made of silver-anodised aluminium.
Technical specifications
- Factory colour
Silver (metallic)
- Connection method
E DAT module
- Height
483 mm
- Rack unit
1 U
- Port
24 ports
- Rack size
483 mm (19")
CAT 6A
- Patch panel design
Equipped
- Connections
24 x RJ-45 female24 ports
- Transfer rate
10 GBit/s
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 973708 Metz Connect 130920-E 24 ports Network patch panel 483 mm (19") CAT 6A 1 U Silver (metallic) Equipped
User & Safety Instructions
User & Safety Instructions 973708 Metz Connect 130920-E 24 ports Network patch panel 483 mm (19") CAT 6A 1 U Silver (metallic) Equipped
User & Safety Instructions 973708 Metz Connect 130920-E 24 ports Network patch panel 483 mm (19") CAT 6A 1 U Silver (metallic) Equipped
Description
The BTR patch-field offers space for up to 24 E-DAT modules, which are not included in the delivery scope. The patch field is ideally suited for mounting in 48.26 cm (19“) network cabinets.
Thereby mainly the later fitting of modules is especially comfortable, since the individual modules can be mounted from the front through the support frame. The perfect cable guide and strain relief is ensured by the appropriate bracket at the support frame.
Thereby mainly the later fitting of modules is especially comfortable, since the individual modules can be mounted from the front through the support frame. The perfect cable guide and strain relief is ensured by the appropriate bracket at the support frame.
Features
- All fully shielded modules connected with the help of earthing rails
- CAT 6a-certified
- Module bracket made of plastic with dust-protection flaps
- Viewing window for labelling insert.
Scope of delivery
- Patch field
- 24x E-DAT module
- 1x labelling arc
- Earthing bolts with nut and tooth washer
- Grounding cable (approx. 30 cm)
- Operating instructions.
