PCE Power Twist 045-6 CEE plug 125 A 5-pin 400 V 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 84.03 / piece)
€ 84.03
plus VAT.
Highlights & Details
CEE PLUG 125 A IP67
- IP67
- Extremely robust
- This text is machine translated.
Technical specifications
- Product type
CEE plug
- Features
Extremely robust
- Nominal voltage
400 V
- Nominal current
125 A
- Nominal current - rounded value
125 A
- Type A
Screws
- Type B
CEE plug
- Cores
5
IP67
- Factory colour
Red
- Dim
(W x H) 131.0000 mm x 131.0000 mm
- Width
131.0000 mm
- Height
131.0000 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 613478 PCE Power Twist 045-6 CEE plug 125 A 5-pin 400 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 613478 PCE Power Twist 045-6 CEE plug 125 A 5-pin 400 V 1 pc(s)
Description
Features
- CEE-Plug 125A 5p 6h IP67 Power TWIST<>
- : PA6
- Pole number<>: 5 (3P+N+PE) br Time position: 6h<><>
- : 200/346V~ - 240/415V~ / 50+60Hz br Contacts: Nickel-plated brass, with pilot contact pin br Connection technology: Frame terminals with screws br<>Protection type: IP66/IP67
