Image similar
Phoenix Contact 1987724 Screw terminal 4.00 mm² Number of pins 2 Green 250 pc(s)
Product type
Screw terminal
CS
5.00 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 250 pc(s))
Total (€ 0.56 / piece)
€ 139.99
incl. VAT
14-day return policy included
Highlights & Details
PCB terminal block PT 2,5/ 2-5,0-V
- Content 250 pc(s)
Technical specifications
- Type
PT 2,5/ 2-5,0-V
- Product type
Screw terminal
- Features
+ wire protector
- CS
5.00 mm
- Pins per row
2
- Number of pins
2
- Series
PT
- Stripping length (max.)
6.50 mm
- Connection
Screw terminal
Print
- Nominal current
32 A
- Cross section (flexible) (min.)
0.50 mm²
- Nominal current - rounded value
32 A
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
4.00 mm²
- Cross section (inflexible) (max.)
4.00 mm²
- AWG (min.)
20
- Connector orientation
Perpendicular (to the PCB)
- AWG max.
10
- Contact material
Tin plated
- Factory colour
Green
- Actuation direction
Parallel (to the PCB)
- Manufacturer part #
1987724
- Industrial packaging
Yes
- Content
250 pc(s)
- Nominal voltage
400 V
- Width
13.50 mm
- Height
13.10 mm
- Length
10.00 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 566660 Phoenix Contact 1987724 Screw terminal 4.00 mm² Number of pins 2 Green 250 pc(s)
User & Safety Instructions
User & Safety Instructions 566660 Phoenix Contact 1987724 Screw terminal 4.00 mm² Number of pins 2 Green 250 pc(s)
Description
PCB terminal block, Nominal current: 32 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 2, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 90 °, Color: green
