Image similar
Phoenix Contact 3073953 Fuse box feed-through terminal 12 mm Screws Black 50 pc(s) Piece
Packaging type
Piece
Product type
Fuse box feed-through terminal
Connection
Screws
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
16 mm²
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 20.10 / piece)
€ 1,005.00
incl. VAT
14-day return policy included
Highlights & Details
Fuse terminal block 3073953
- UK 10-DREHSI-EX (5X20)
Technical specifications
- G-fuse 5x20 mm
- Packaging type
Piece
- Product type
Fuse box feed-through terminal
- Connection
Screws
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (inflexible) (max.)
16 mm²
- Clamp width
12 mm
- No. of rows
1
- Factory colour
Black
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Nominal voltage
500 V
- Manufacturer part #
3073953
- Content
50 pc(s)
- Type
UK 10-DREHSI-EX (5X20)
- Dim
(L x W x H) 62 x 12 x 57.2 mm
- Width
12 mm
- Height
57.2 mm
- Length
62 mm
- Flammability rating
V2
- Connector colour
Black
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1831005 Phoenix Contact 3073953 Fuse box feed-through terminal 12 mm Screws Black 50 pc(s) Piece
Description
Bridged with the fixed bridge FBI....
This text is machine translated.
This text is machine translated.
