Phoenix Contact IB IL SGI 2/F-PAC 2878638 PLC add-on module 24 V DC
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 449.58 / piece)
€ 449.58
plus VAT.
14-day return policy included
Technical specifications
- Product type
PLC add-on module
- Type
IB IL SGI 2/F-PAC
- No. of analogue inputs
2
- No. of analogue outputs
2
- No. of digital inputs (max.)
2
- No. of inputs (max.)
2
- No. of outputs (max.)
2
- No. of inputs
2 x
- No. of outputs
2 x
- Max. output current per channel
55 mA
- Operating voltage
24 V DC
- Height
136 mm
- Length
71.5 mm
- Width
48.8 mm
IP20
- Dim
(L x W x H) 71.5 x 48.8 x 136 mm
- Connection
Inline data shunter
- Field bus system
In-line local bus
- Manufacturer part #
2878638
- Max. ambient temperature
55 °C
- Min. ambient temperature
-25 °C
- Logic voltage UL
7.5 V DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 193999 Phoenix Contact IB IL SGI 2/F-PAC 2878638 PLC add-on module 24 V DC
User & Safety Instructions
User & Safety Instructions 193999 Phoenix Contact IB IL SGI 2/F-PAC 2878638 PLC add-on module 24 V DC
Description
Inline analog strain gauge input terminal, complete with accessories (plug and labeling field), 2 fast inputs, 4, 6-conductor connection method
