Name: Plustek SmartOffice PS288 Pro Document scanner 600 x 600 dpi 30 pages/min USB A (USB 2.0)
Brand: Plustek
SKU: 3836280
Price: 335 EUR
Availability: InStock

A compact document scanner with a front paper tray and 'Plustek SmartOffice PS30 Pro' branding on the lid.

A Fujitsu document scanner with a silver top cover and black base, shown front-left on a white background.<br>

Desktop paper shredder with open feed tray and clear front output tray on a white background.

Portable paper shredder with clear top feed slot, black body, and small control panel on the front<br>

Rear view of a black electronic device with a handle, showing a USB port, power jack, and on/off switch on the back panel.

1/5

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Thu 12 Nov

4 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 335.00 / piece)

€ 335.00

incl. VAT

Only 4 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

SmartOffice PS288 Pro document scanner

CUSTOM JOB PROFILES – Save your preferred settings as a quick dial to process documents much faster and easier.
POWERFUL IMAGE OPTIMIZATION – automatic rotation, blank page removal, edge balancing, merging or separating pages, removal of punched holes, watermarks and more for clean, professional scan results.
INTEGRATED BARCODE DETECTION – Detects up to 12 barcode types to automatically capture data, name files, and intelligently separate documents.
DYNAMIC AUTO-NAMING – DYNAMIC AUTO-NAMING – extract relevant data reliably and automatically name files from scanned or imported documents. An immediate upgrade for your workflow.
HIGH SCANNING SPEED - Compact design for one-and double-sided scanning of documents, business cards and receipts in a passage of up to 30 pages per minute, automatic 50-page document feeder and support of documents up to 508 cm length.

Technical specifications

Integrated barcode reader (recognizes up to 12 barcode types including QR codes)
Automatic file naming & data extraction
Automatic image element optimization (blank page removal, edge compensation, hole spacing)

Product type: Document scanner

Scan function: Documents
Calling cards
Plastic cards

Optical resolution: 600 x 600 dpi

Scanning speed: 30 pages/min

Scan area width (min.): 216 mm

Scan area (max.): 356 mm

Max. grammage: 105 g/m²

Document feed: 50 Sheet

Sensor type: CIS

Interfaces: USB A (USB 2.0)

Duplex unit: Yes

Traversing light unit: No

Feeder: Yes

Flatbed unit: No

Width: 263 mm

Height: 148 mm

Depth: 127.5 mm

Dim: (W x H x D) 263 x 148 x 127.5 mm

Weight: 1.66 kg

Factory colour: Black

Documents & Downloads

Datasheet

Datasheet 3836280 Plustek SmartOffice PS288 Pro Document scanner 600 x 600 dpi 30 pages/min USB A (USB 2.0)

User & Safety Instructions

User & Safety Instructions 3836280 Plustek SmartOffice PS288 Pro Document scanner 600 x 600 dpi 30 pages/min USB A (USB 2.0)

Description

The Plustek SmartOffice PS288 Pro – accelerate your workflow. Like a professional.
Work smarter with fast duplex scanning and intuitive tools to simplify everyday document tasks.

This text is machine translated.

Features

Image sensor: CIS x 2 (duplex scanner)
Light type: LED
Optical resolution 600 dpi
Interpolated resolution: 1200 dpi
600 x 1200 dpi hardware resolution
Scanning method: Colour: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
Black & White 1-bit
ADF Capacity: 1. 50 sheets (A4/ letter, 70 g/㎡ or 18 lbs.), Max. Thickness below 5 mm (0.2").
2. 20 sheets (business card).
3. Plastic cards, max. Thickness below 1.2 mm.
Note: The maximum ADF capacity varies depending on the paper weight.
Scanning speed (ADF): 30 ppm / 60 ipm (grayscale, 200 & 300 dpi, A4)
30 ppm/ 60 ipm (black/white, 200 & 300 dpi, A4)
30 ppm/ 60 ipm (color, 200 & 300 dpi, A4)
Note: Scan results and speeds may vary depending on CPU and available memory.
Scan area (W x L): Maximum: 216 x 5080 mm (8.5" x 200")
Minimum: 13.2 x 13.2 mm (0.52” x 0.52”)
Supported paper size (W x L) Maximum: 220 x 5080 mm (8.66" x 200")
Minimum: 63.5 x 50.8 mm (2.5” x 2”)
Grammage (paper weight): 50 to 105 g/m²
Daily volume (pages): 4.000
Duration of the roller (scans): 300.000
Service life of the rubber pad (scans): 50.000
3 keys: Up, down, scan.
9 function buttons. All adaptable.
Power supply 24 Vdc/ 0.75 A.
USB 2.0 type B connection
Net weight: 1.66 kg (3.66 lbs)
Dim. (W x D x H): 263 x 128 x 148 mm (10.36" x 5.02" x 5.83")
Interface: TWAIN compatible

Scope of delivery

Scanners
PSU
Plustek SmartScan software
Plustek OCR (for Windows)
(Supported by ABBYY® FineReader®)

Hints

Scan speed (if stated) refers to A4-sized documents.

System requirements

Windows 7 / 8 / 10 / 11
2.0 GHz CPU processor or higher[1][2][3]
[1]Windows recommended: 2.8 GHz Intel® Core™ i5 processor with 4 CPU cores or higher
[2]Supports Mac Intel and M1-based processors
[3]PowerPC compatibility not available
At least 4 GB RAM (8 GB or more recommended)
6 GB hard disk storage for the program installation
Display dimensions of 1024 x 768 or higher
