Relay Module PLC-RSC- 24DC/ 1AU/SEN 2966317 Phoenix Contact
Product type
Interface relay
Contact type
1 maker
Nominal voltage
24 V DC
Switching voltage (max.)
36 V DC
30 V AC
Switching current (max.)
50 mA
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 10 pc(s))
Total (€ 14.00 / piece)
€ 139.99
incl. VAT
14-day return policy included
Highlights & Details
Relay Module PLC-RSC- 24DC/ 1AU/SEN
- Industrial packaging, pack of 10
Technical specifications
- Product type
Interface relay
- Type
PLC-RSC- 24DC/ 1AU/SEN
- Connection
Screw terminal
- Contact type
1 maker
- Contact material
AgSnO + gold plating
- Nominal voltage
24 V DC
- Switching voltage (max.)
36 V DC
30 V AC
- Switching current (max.)
50 mA
- Features
+ LED
+ flyback diode
+ reverse polarity protection
IP20
- Max. temperature
+60 °C
- Min. temperature
-40 °C
- Depth
94 mm
- Width
6.2 mm
- Height
80 mm
- Dim
(W x H x D) 6.2 x 80 x 94 mm
- Content
10 pc(s)
- Industrial packaging
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 706812 Relay Module PLC-RSC- 24DC/ 1AU/SEN 2966317 Phoenix Contact
User & Safety Instructions
User & Safety Instructions 706812 Relay Module PLC-RSC- 24DC/ 1AU/SEN 2966317 Phoenix Contact
Description
PLC sensor relay, consisting of base terminal block PLC-BSC...SEN with screw connection and pluggable miniature relay with multi-layer contact, for assembly on DIN rail NS 35/7.5, 1 N/O contact, input voltage 24 V DC
