Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

Blue, rectangular plastic component with six circular holes arranged in two vertical rows, used as a construction or connection part.
Packaging type
Piece
Product type
Busbar
Length
1675 mm
Material
Copper
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 20 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (1 m = € 196.42)
€ 329.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Packaging type

Piece

Product type

Busbar

Material

Copper

Length

1675 mm

Content

1 pc(s)

Type

LVS04516

60

Flat

5 mm

Untreated

1675 m

800 A

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 2936367 Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

Datasheet 2936367 Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 2936367 Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

Information

Information 2936367 Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

Information 2936367 Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

Information 2936367 Schneider Electric LVS04516 LVS04516 Busbar Copper 1675 mm 1 pc(s) Piece

Description

PrismaSet P. Linergy BS vertical copper busbar with a rail size of 60 x 5 mm, with holes diameter 10 mm at 25 mm intervals, a permissible current of 800 A with a degree of protection ? IP31 Or a permissible current of 750 A with a degree of protection gt/ IP31, or a permissible current of 1400 A with a degree of protection ? IP31 when using two rails per phase. Or a permissible current of 1250 A with degree of protection gt/ IP31 when using two rails per phase, in a side busbar compartment of 150 mm width or a permissible current of 800 A with degree of protection up to IP31, or a permissible current of 750 A with degree of protection from IP31, on the back of a control panel, at an ambient temperature of 35 °C and a length of 1675 mm
