Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

A light blue rectangle with six white circles cut out, evenly arranged in two columns and three rows.
Packaging type
Piece
Product type
Busbar
Length
1675 mm
Material
Copper
Max. temperature
35 °C
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 13 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (1 m = € 295.52)
€ 495.00
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Packaging type

Piece

Product type

Busbar

Material

Copper

Max. temperature

35 °C

Length

1675 mm

Content

1 pc(s)

Type

LVS04525

50

Flat

10 mm

Untreated

1675 m

1200 A

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 2936376 Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

Datasheet 2936376 Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 2936376 Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

Information

Information 2936376 Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

Information 2936376 Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

Information 2936376 Schneider Electric LVS04525 LVS04525 Busbar Copper 1675 mm 1 pc(s) Piece

Description

PrismaSet P. Linergy BS vertical copper busbar with a rail size of 50 x 10 mm, with holes diameter 10 mm at 25 mm intervals, a permissible current of 1200 A with a degree of protection ? IP31 Or a permissible current of 1080 A with a degree of protection gt/ IP31, or a permissible current of 2050 A with a degree of protection ? IP31 when using two rails per phase. Or a permissible current of 1850 A with degree of protection gt/ IP31 when using two rails per phase, in a 150 mm wide side busbar compartment or a permissible current of 1080 A with degree of protection gt/ IP31, on the back of a control panel, at an ambient temperature of 35 °C and a length of 1675 mm.

This text is machine translated.
