SIBA 189140.2,5 T SMD fuse 2.50 A 250 V DC, 277 V AC Time delay -T- Content 10 pc(s)
Product type
SMD fuse
Nominal voltage
250 V DC
277 V AC
Nominal current - rounded value
2.5 A
Release characteristics
Time delay -T-
Content
10 pc(s)
Datasheet (PDF)
Part number:
Item no:
Number (Package size 10 pc(s))
Total (€ 6.49 / piece)
€ 6.49
incl. VAT
Only 2 Set(s) available
Highlights & Details
SIBA G-fuse link 6.3X32 mm 189140 slow-blow 500VAC 2.5A
- Ceramic tube, opaque with solvent filling
Technical specifications
- Casing material: Ceramic
- Material connections: Copper alloy, silver-plated
- Melting Integral: 0.098 A²/s.
- Rated breaking capacity 500 A.
- Voltage drop 900 mV
- Soldibility 260 °C / 10 s
- Product type
SMD fuse
- Nominal voltage
250 V DC
277 V AC
- Nominal current
2.50 A
- Nominal current - rounded value
2.5 A
- Release characteristics
Time delay -T-
- Content
10 pc(s)
- Type
189140.2,5 T
- Weight
2.4 g
Documents & Downloads
Datasheet
Datasheet 3843446 SIBA 189140.2,5 T SMD fuse 2.50 A 250 V DC, 277 V AC Time delay -T- Content 10 pc(s)
User & Safety Instructions
User & Safety Instructions 3843446 SIBA 189140.2,5 T SMD fuse 2.50 A 250 V DC, 277 V AC Time delay -T- Content 10 pc(s)
Description
As primary protection in devices
