Sunon EF80252B1-1000U-A99 Axial fan 24 V DC (L x W x H) 80 x 80 x 25 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
24 V DC
No. of wires
2
Power
1.56 W
Type of bearing
Ball bearing
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.45
5
6% = € 0.32
€ 5.13
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 5.45 / piece)
€ 5.45
plus VAT.
Technical specifications
- Product type
Axial fan
- Type
EF80252B1-1000U-A99
- Nominal voltage
24 V DC
- No. of wires
2
- Min. operating voltage
8 V DC
- Max. operating voltage
27.6 V DC
- Operating voltage
8 - 27.6 V DC
- Max. current consumption
75 mA
1.56 W
- Type of bearing
Ball bearing
- Rotational speed
3200 U/min
- Noise emission (max.)
33 dB
- Connection
Open cable ends
- Cable length
0.315 m
- Factory colour
Black
- Material
PBT
Thermoplastic
70,000 hours
- Weight
75 g
- Min. temperature
-10 °C
- Max. temperature
+70 °C
- Length
80 mm
- Width
80 mm
- Height
25 mm
- Dim
(L x W x H) 80 x 80 x 25 mm
Documents & Downloads
Datasheet
Datasheet 2636036 Sunon EF80252B1-1000U-A99 Axial fan 24 V DC (L x W x H) 80 x 80 x 25 mm
User & Safety Instructions
User & Safety Instructions 2636036 Sunon EF80252B1-1000U-A99 Axial fan 24 V DC (L x W x H) 80 x 80 x 25 mm
