Sunon MF80252V11000UA99 Axial fan 24 V DC 69.64 m³/h (L x W x H) 80 x 80 x 25 mm

A black computer fan by Sunon with technical specifications: Model EE80251BX-000U-A99, DC 12V, 1.8W, manufactured in China.
Image similar
Product type
Axial fan
Nominal voltage
24 V DC
Power
1.56 W
Type of bearing
Vapo (magnetic)
Air flow rate
69.64 m³/h
Datasheet (PDF)
EAN:
Part number:
Item no:
Available soon
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 7.99 / piece)
€ 7.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Product type

Axial fan

Type

MF80252V11000UA99

Nominal voltage

24 V DC

Max. operating voltage

24 V

Operating voltage

24 V (max)

Max. current consumption

65 mA

1.56 W

Type of bearing

Vapo (magnetic)

Rotational speed

3200 U/min

Noise emission (max.)

33 dB

Air flow rate

69.64 m³/h

Connection

Open end cable

Cable length

0.30 m

Material

Thermoplastic

PBT

Min. temperature

-10 °C

Max. temperature

+70 °C

Length

80 mm

Width

80 mm

Height

25 mm

Dim

(L x W x H) 80 x 80 x 25 mm

Documents & Downloads

Datasheet

Datasheet 2357993 Sunon MF80252V11000UA99 Axial fan 24 V DC 69.64 m³/h (L x W x H) 80 x 80 x 25 mm
